Federal Pacific NEJ231225NA - 225A 3 Pole Molded Case Switch
Re-Certified
Quantity
Description
Operating as a dedicated manual disconnect, this three-phase 225A switch allows safe isolation of industrial equipment. It contains no automatic trip elements, functioning purely for switching purposes. The unit integrates perfectly into older Federal Pacific panelboards requiring bolt-on N-frame components. This exact-match replacement helps engineers avoid costly enclosure upgrades. Rated for 10kA short-circuit withstand when properly protected, it handles up to 250VDC applications.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NEJ231225NA-R |
| Series | NEJ |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Federal Pacific Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Al/Cu) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs |
| Standards | UL 489, NEMA AB-1 |
| Approval | UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic (Disconnect) |
