Siemens / ITE FJ3S22500S01 - 225A 3 Pole Molded Case Switch
Re-Certified
Quantity
Description
Operating as a dedicated isolation device, the Siemens FJ3S22500S01 is a 225-amp molded case switch featuring a built-in shunt trip. This allows users to remotely open the circuit for safety or maintenance, while still providing manual disconnect functionality. This 3-pole unit mounts into legacy Siemens F-frame enclosures, including F1, F2, and SB series switchboards. It provides an exact fit for older systems where the newer FXD63S250 would require additional accessory kits.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | FJ3S22500S01-R |
| Series | FJ |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 25kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens / ITE F1, F2, SB1, SB2, SB3 Panelboards and Switchboards |
| Wire Gauge | 6 AWG - 350 kcmil (Cu/Al) |
| Max Wire | 350 kcmil |
| Min Wire | 6 AWG |
| Trip Technology | Magnetic Only |
|---|
| Available Options | Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Shunt Trip |
| Standards | UL 489, NEMA AB-1, CSA C22.2 No. 5, UL 1087 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Automatic (Disconnect), Non-Interchangeable Trip |
