ABB / General Electric TEB122070 Molded Case Circuit Breaker
- 70A
- 2 Pole
- Bolt-On
ABB / General Electric
TEB122070
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
TEB122070
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TEB122070 - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric TEB122070 - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEB122070 |
| Series | TEB |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 10kA @ 120/240VAC, 5kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, Spectra Series Panelboards |
| Wire Gauge | 6-1/0 AWG (Cu), 4-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG (Cu), 4 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (TCAL15) |
| Standards | HACR, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Common Trip, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Sold out
Quantity
ABB / General Electric TEB122070 - 70A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEB122070-R |
| Series | TEB |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 10kA @ 120/240VAC, 5kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, Spectra Series Panelboards |
| Wire Gauge | 6-1/0 AWG (Cu), 4-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG (Cu), 4 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (TCAL15) |
| Standards | HACR, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Common Trip, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Similar Items
ABB / General ElectricTEB122060
60A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTEB122090
90A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTEB122050
50A 2 Pole Molded Case Circuit Breaker
Description
Manufactured for robust industrial power distribution, the TEB122070 delivers thermal-magnetic trip functions for commercial facilities. This bolt-on E-frame device installs into GE A-Series and Spectra Series panelboards. It comes equipped with TCAL15 load lugs and serves as a substitute for TED124070 or THED124070 models. Delivering a 10kA interrupting capacity at 240VAC, the breaker ensures reliable fault clearing. It features a trip-free mechanism and is fully HACR rated.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEB122070 |
| Series | TEB |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 240VAC, 10kA @ 120/240VAC, 5kA @ 125/250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | GE A-Series Panelboards, Spectra Series Panelboards |
| Wire Gauge | 6-1/0 AWG (Cu), 4-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG (Cu), 4 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (TCAL15) |
| Standards | HACR, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Common Trip, Non-Interchangeable Trip, Quick-Make/Quick-Break, Trip-Free Mechanism |
Product FAQs
5 answersWhat panelboards are compatible with the TEB122070?
This E150 line, E-frame bolt-on breaker is designed for installation in GE A-Series and Spectra Series panelboards.
Is the TEB122070 suitable for reverse feed applications?
Yes, GE TEB series circuit breakers are suitable for reverse feed. The line and load connections can be swapped without affecting the thermal-magnetic trip functions.
Are GE and ABB TEB122070 breakers the same?
Yes. Following ABB's acquisition of GE Industrial Solutions, TEB series breakers may feature either GE or ABB branding. They are identical in form, fit, and function and are fully interchangeable.
Can the TEY series be used as a direct replacement for the TEB122070?
No. While both are used in GE panelboards, the TEB is an E150 line molded case circuit breaker, whereas the TEY is a miniature circuit breaker. They have different physical dimensions and mounting requirements.
Is the TEB122070 HACR rated?
Yes, GE TEB series breakers 15 amps and above, including this 70-amp model, are UL listed as HACR type for use with heating, air conditioning, and refrigeration equipment.
