ABB / General Electric TEY370 Miniature Circuit Breaker
- 70A
- 3 Pole
- Bolt-On
ABB / General Electric
TEY370
Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
TEY370
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric TEY370 - 70A 3 Pole Miniature Circuit Breaker
New
Quantity
Quantity
ABB / General Electric TEY370 - 70A 3 Pole Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEY370-R |
| Series | TEY |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 480Y/277VAC, 250VDC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 14kA @ 480Y/277VAC, 10kA @ 250VDC, 65kA @ 120/240VAC |
| Frame Type | TEY |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards, GE AE Lighting Panelboards, GE AS Lighting Panelboards |
| Wire Gauge | 4 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Mounting Base |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break |
Quantity
ABB / General Electric TEY370 - 70A 3 Pole Miniature Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEY370 |
| Series | TEY |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 480Y/277VAC, 250VDC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 14kA @ 480Y/277VAC, 10kA @ 250VDC, 65kA @ 120/240VAC |
| Frame Type | TEY |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards, GE AE Lighting Panelboards, GE AS Lighting Panelboards |
| Wire Gauge | 4 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Mounting Base |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break |
Similar Items
80A 3 Pole Miniature Circuit Breaker
60A 3 Pole Miniature Circuit Breaker
ABB / General ElectricTEY360ST12
60A 3 Pole Miniature Circuit Breaker
Description
Providing robust protection for commercial and industrial systems, the GE TEY370 is a 3-pole, 70A miniature circuit breaker. It mounts into GE A-Series, AE, and AS lighting panelboards using a secure bolt-on connection. The Q-Line breaker features fixed thermal-magnetic trip technology with a 14kAIC interrupting rating at 480Y/277VAC. It includes load side lugs, a quick-make/quick-break mechanism, and is HACR rated for use with heating and cooling equipment.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TEY370 |
| Series | TEY |
| Amperage | 70A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 240VAC, 480Y/277VAC, 250VDC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 65kA @ 120VAC, 65kA @ 240VAC, 14kA @ 480Y/277VAC, 10kA @ 250VDC, 65kA @ 120/240VAC |
| Frame Type | TEY |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Lighting Panelboards, GE AE Lighting Panelboards, GE AS Lighting Panelboards |
| Wire Gauge | 4 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Mounting Base |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break |
Product FAQs
5 answersWhich electrical panelboards are compatible with the TEY370?
The TEY370 is designed to mount in GE A-Series lighting panelboards, including the AE and AS types. It features a bolt-on connection that attaches directly to the panel bus.
What do the Long-Time and Instantaneous (LI) functions indicate on this breaker?
The LI trip unit provides two types of protection. The Long-Time (L) function responds to sustained electrical overloads by monitoring thermal conditions, while the Instantaneous (I) function uses magnetic response to trip immediately during a short circuit. On the TEY370, both settings are fixed.
Are there higher interrupting capacity alternatives available for the TEY370?
Yes. If your system requires a higher short circuit rating than the 14kAIC offered by the standard TEY370 at 480/277VAC, you can use the TEYF370 (18kAIC), TEYD370 (25kAIC), TEYH370 (35kAIC), or TEYL370 (65kAIC) models.
What wire types and sizes can be connected to the load terminals?
The factory-installed lugs on the TEY370 accept either copper or aluminum conductors. They are rated for wire sizes ranging from 4 AWG up to 1/0 AWG.
Does the TEY370 support direct current (DC) circuits?
Yes. In addition to its AC ratings, this miniature circuit breaker carries a 250VDC rating with a 10kA interrupting capacity, making it suitable for specific DC applications.
