ABB / General Electric THQB1130GFEP GFEP Miniature Circuit Breaker
- 30A
- 1 Pole
- Bolt-On
ABB / General Electric
THQB1130GFEP
GFEP Miniature Circuit Breaker
Brand
ABB / General Electric
SKU
THQB1130GFEP
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQB1130GFEP - 30A GFEP Miniature Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTHQB1115GFEP
15A GFEP Miniature Circuit Breaker
ABB / General ElectricTHQB2130GFEP
30A GFEP Miniature Circuit Breaker
ABB / General ElectricTHQL1130GFEP
30A GFEP Miniature Circuit Breaker
Description
Engineered for commercial facilities, the GE THQB1130GFEP provides reliable 30mA ground fault equipment protection. This single-pole, 30A miniature circuit breaker prevents damage to machinery by detecting low-level leakage currents. The bolt-on design installs securely into GE A-Series panelboards. It features a non-interchangeable thermal-magnetic trip unit and accepts 14-8 AWG copper or 12-8 AWG aluminum wire. Rated for 10kAIC at 120/240VAC, this Q-Line breaker is HACR rated.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQB1130GFEP |
| Series | THQB |
| Amperage | 30A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQB |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE A-Series Panelboards |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | GFEP |
|---|---|
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
| Accessories | Load Side Lugs Included |
| Standards | HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip, Quick-Make/Quick-Break |
Product FAQs
6 answersWhich panelboards are compatible with the THQB1130GFEP circuit breaker?
This bolt-on breaker is designed exclusively for GE A-Series and ReliaGear panelboards that accept THQB or Q-Line bolt-on breakers. It cannot be used in standard residential load centers that require plug-on THQL breakers.
What is the difference between GFEP and a standard GFCI breaker?
GFEP (Ground Fault Equipment Protection) breakers, like the THQB1130GFEP, have a 30mA trip threshold designed to protect machinery, heat trace cables, and equipment from electrical damage. Standard Class A GFCI breakers have a 5mA threshold intended for personnel shock protection.
How is the neutral connection made for this GFEP breaker?
The THQB1130GFEP features a pigtail neutral wire that must be connected directly to the panel neutral bus bar to ensure the ground fault sensing circuitry functions correctly.
Is there a difference between the ABB and GE versions of the THQB1130GFEP?
No. ABB acquired GE Industrial Solutions, so this breaker may arrive with either ABB or GE branding. The form, fit, function, and UL listings remain identical regardless of the logo on the label.
Can I install this bolt-on breaker in a panel made by a different manufacturer?
No. The THQB1130GFEP is only UL listed for use in compatible GE or ABB panelboards. Mixing breaker brands in commercial panels violates UL listings and electrical codes.
What applications typically require a 30mA GFEP breaker?
GFEP breakers are commonly required for outdoor heat trace systems, snow melting equipment, and dedicated industrial machinery where normal operational leakage current might cause nuisance tripping on a standard 5mA GFCI breaker.
