ABB / General Electric THQB2170ST1 Molded Case Circuit Breaker
- 70A
- 2 Pole
- Bolt-On
Quantity
ABB / General Electric THQB2170ST1 - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
Description
Part of the Q-Line family, the GE THQB2170ST1 is a 2-pole, 70-amp molded case circuit breaker designed for commercial electrical systems. It provides robust thermal-magnetic protection for branch circuits. This bolt-on breaker installs into GE A-Series panelboards and AQ lighting panels. It accepts 6-1/0 AWG copper or 4-1/0 AWG aluminum wire via standard box lug terminals. Rated for 10kAIC at 120/240VAC, this unit features a factory-installed shunt trip for remote disconnect capabilities.Specifications
| Brand | ABB / General Electric |
|---|---|
| Series | THQB |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQB |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | GE A-Series Panelboards, GE AQ Lighting Panels |
| Wire Gauge | 6-1/0 AWG (Cu), 4-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 6 AWG (Cu), 4 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Auxiliary Switch, Undervoltage Release, Padlock Attachment |
|---|---|
| Accessories | Shunt Trip |
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break, Non-Interchangeable Trip |
Product FAQs
6 answersWhat panelboards are compatible with the THQB2170ST1 circuit breaker?
This bolt-on breaker is designed specifically for commercial applications, installing directly into GE A-Series panelboards and GE AQ lighting panels.
What does the ST1 suffix mean in the THQB2170ST1 part number?
The ST1 suffix indicates that the breaker includes a factory-installed 120VAC shunt trip accessory. This feature allows the breaker to be tripped remotely via an external control signal for emergency shutdowns or automated control.
Can I use the THQB2170ST1 in a standard GE residential load center?
No. The THQB series features a bolt-on connection designed for commercial panels. Standard GE residential load centers require plug-on breakers, such as the THQL series.
Will my THQB2170ST1 breaker arrive branded as ABB or General Electric?
Following ABB's acquisition of GE Industrial Solutions, Q-Line breakers may feature either ABB or GE branding. The form, fit, function, and panel compatibility remain exactly the same regardless of the label.
How does the bolt-on connection of the THQB2170ST1 differ from plug-on breakers?
Bolt-on breakers like the THQB2170ST1 physically screw into the panel's bus bar. This creates a highly secure, vibration-resistant connection typically required in commercial and industrial environments, unlike plug-on breakers that simply snap into place.
Does the THQB2170ST1 include ground fault or arc fault protection?
No. This is a standard thermal-magnetic breaker providing long-time and instantaneous (LI) overcurrent protection. It does not include GFCI or AFCI capabilities.
