ABB / General Electric THQC2115WL Molded Case Circuit Breaker
- 15A
- 2 Pole
- DIN Rail
ABB / General Electric
THQC2115WL
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
THQC2115WL
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQC2115WL - 15A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
ABB / General ElectricTHQC2120
20A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTHQC2125
25A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTHQC2125WL
25A 2 Pole Molded Case Circuit Breaker
Description
Designed for versatile feed-thru applications, the GE THQC2115WL is a 2-pole, 15-amp molded case circuit breaker. The "WL" designation means it includes both line and load side lugs for custom wiring. This Q-Line breaker installs onto standard 35mm DIN rail, providing a secure fit for OEM panels and commercial enclosures. Its compact width helps conserve interior space.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQC2115WL |
| Series | THQC |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | DIN Rail |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Frame Type | THQC |
|---|---|
| Terminal Type | Lugs |
| For Use With | 35mm DIN Rail, OEM Panels, Enclosures |
| Wire Gauge | 14-8 AWG (Cu), 12-8 AWG (Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Shunt Trip, Auxiliary Switch |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 10C to 50C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break, Visual Trip Indicator, Non-Interchangeable Trip |
Product FAQs
6 answersWhat is the difference between GE THQC, THQL, and THQB circuit breakers?
While they are all part of the GE Q-Line family, they have different mounting configurations. THQC breakers feature lug-to-lug connections and mount on a 35mm DIN rail or base mount. THQL breakers are plug-in types for standard load centers, and THQB breakers are bolt-on types for commercial panelboards.
Can I use the THQC2115WL in a standard GE residential load center?
No. The THQC2115WL is a lug-to-lug, DIN rail-mounted breaker designed for OEM panels and commercial enclosures. Standard GE residential load centers require plug-in THQL or half-inch THQP breakers.
What does the "WL" suffix mean on the THQC2115WL catalog number?
The "WL" suffix indicates that the circuit breaker comes factory-equipped with both line and load side lugs for custom wiring applications.
Does the THQC2115WL feature a common trip mechanism?
Yes. It includes an internal common trip linkage, ensuring that if an overload or short circuit is detected on one pole, both poles will trip simultaneously to safely disconnect the circuit.
How can I tell if the THQC2115WL has tripped?
The breaker features a visual trip indicator where the handle moves to a center position between ON and OFF when a fault occurs. To reset it, move the handle fully to the OFF position before turning it back ON.
Why might my THQC2115WL arrive with ABB branding instead of GE?
ABB acquired GE Industrial Solutions in 2018. As a result, Q-Line breakers like the THQC2115WL may feature either ABB or GE branding, but the product remains identical in form, fit, and function.
