Siemens / ITE CF3B015 Molded Case Circuit Breaker
- 15A
- 3 Pole
- Bolt-On
Siemens / ITE
CF3B015
Molded Case Circuit Breaker
Brand
Siemens / ITE
SKU
CF3B015
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens / ITE CF3B015 - 15A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
30A 3 Pole Molded Case Circuit Breaker
40A 3 Pole Molded Case Circuit Breaker
50A 3 Pole Molded Case Circuit Breaker
Description
Operating as a highly effective current-limiting device, this 15A molded case circuit breaker protects industrial systems from severe electrical faults. It incorporates integral Amp-Trap fuses to drastically reduce let-through energy during short circuits. Engineered for bolt-on installation, the unit fits perfectly into compatible Siemens switchboards and motor control centers.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | CF3B015-R |
| Series | CF |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 200kA @ 480VAC, 100kA @ 600VAC, 100kA @ 250VDC |
| Frame Type | CF |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Switchboards, Motor Control Centers |
| Wire Gauge | 14-1/0 AWG (Cu), 12-1/0 AWG (Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Line Side Lugs |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, Integral Amp-Trap Fuses, High Interrupting Capacity |
| Special Features | Current Limiting (Integrally Fused) |
Product FAQs
5 answersWhat equipment is the CF3B015 compatible with?
This bolt-on CF frame breaker is designed for installation in Siemens and legacy ITE switchboards, as well as motor control centers (MCCs) that accept C-frame molded case circuit breakers.
How does the current-limiting feature of the CF3B015 benefit the electrical system?
As a current-limiting breaker, it interrupts fault currents extremely fast, significantly reducing the let-through energy (I2t and Ip). This provides enhanced protection for downstream components and allows for higher series-combination ratings in the switchboard or MCC.
Are ITE and Siemens CF-frame breakers interchangeable?
Yes. Siemens acquired ITE and continued manufacturing many of their legacy product lines under the Siemens brand. A Siemens CF3B015 is a direct, exact replacement for an older ITE CF3B015.
Can I use aluminum wiring with the factory lugs on the CF3B015?
Yes, the factory-installed line and load lugs are dual-rated for both copper and aluminum conductors. They accept 14 to 1/0 AWG copper or 12 to 1/0 AWG aluminum wire. Ensure an appropriate oxide inhibitor is applied when terminating aluminum conductors.
Can this breaker be used in DC applications?
Yes, the CF3B015 is rated for DC systems up to 250VDC with an interrupting capacity of 100kA. When applying this breaker in DC circuits, ensure the wiring configuration complies with the manufacturer instructions for DC pole connections.
