Siemens / ITE E62B060 Molded Case Circuit Breaker
- 60A
- 2 Pole
- Bolt-On
Quantity
Siemens / ITE E62B060 - 60A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Operating at up to 600VAC, this 60-amp molded case circuit breaker is engineered for heavy-duty commercial environments. The E-frame construction utilizes proven thermal-magnetic technology to safeguard critical branch circuits. It fastens securely into classic ITE enclosures as well as Siemens P1, P2, and P3 panelboards without requiring adapters. Facility managers looking for current equivalents can cross-reference the ED62B060 substitute.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | E62B060-R |
| Series | E |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | E6 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, ITE Panelboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5, IEC 60947-2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
7 answersWhich panelboards are compatible with the E62B060 circuit breaker?
This breaker bolts directly into Siemens P1, P2, and P3 panelboards, as well as legacy ITE enclosures, without requiring additional mounting adapters.
What is the modern equivalent for the legacy E62B060?
The Siemens ED62B060 serves as the direct modern substitute for this legacy E-frame model.
Is there a difference between the ITE and Siemens versions of this breaker?
No. Siemens acquired ITE and maintained the same E-frame design. Breakers branded as ITE or Siemens with this catalog number are physically and functionally identical.
What wire sizes and materials are supported by the load terminals?
The factory-installed load side lugs accommodate 10 AWG through 1/0 AWG conductors and are rated for both copper and aluminum wiring.
Does this breaker include the necessary lugs?
Yes, it comes equipped with factory-installed load side lugs. The line side connects directly to the panelboard bus via its bolt-on mounting bracket.
Are the trip settings on the E62B060 adjustable?
No, this breaker features a fixed thermal-magnetic trip unit. Both the long-time and instantaneous trip functions are factory set and cannot be adjusted in the field.
Is this breaker suitable for direct current applications?
Yes, in addition to its standard AC ratings, it is certified for DC systems up to 250VDC, providing a 30kA interrupting capacity for compatible industrial or control circuits.
