Mersen A240R3R Fuse
Quantity
Core Specs
See full specs
Mersen A240R3R Fuse
New
Quantity
Description
Mersen A240R3R Fuse
The Mersen A240R3R is a fuse with a current rating of 100 Amps and a voltage rating of 2400V. It has an interrupting rating of 65kAIC at 2400V. The A240R3R has a clip mounting type and it is used for medium voltage motors and motor controllers.
Specifications
| Amperage | 100 A |
|---|---|
| Voltage | 2400 V |
| Interrupting Rating | 65kA@2.4kV |
| Series | Amp-Trap |
| Mounting Type | Clip |
|---|---|
| Connection Type | Ferrule |
| Terminal Connection | Ferrule |
| Length (in) | 3 |
| Width (in) | 3 |
| Height (in) | 10.88 |
| Approval | UL |
|---|---|
| Body Material | Epoxy |
| Brand | Mersen |
|---|---|
| MPN | A240R3R |
| UPC | 782001800031 |
