Siemens ED21B060 Molded Case Circuit Breaker
- 60A
- 1 Pole
- Bolt-On
Siemens
ED21B060
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED21B060
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED21B060 - 60A 1 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens ED21B060 - 60A 1 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED21B060 |
| Series | ED2 |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC, 5kA @ 125VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Sold out
Quantity
Siemens ED21B060 - 60A 1 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED21B060-R |
| Series | ED2 |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC, 5kA @ 125VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
40A 1 Pole Molded Case Circuit Breaker
30A 1 Pole Molded Case Circuit Breaker
25A 1 Pole Molded Case Circuit Breaker
Description
Built for robust power distribution, the Siemens ED21B060 is a 1-pole, 60A molded case circuit breaker. It features a non-interchangeable thermal-magnetic trip unit, delivering reliable long-time and instantaneous protection with a 10kAIC rating at 120VAC. Designed for seamless integration, this bolt-on breaker mounts into Siemens P1, P2, P3, and Sentron panelboards, as well as SB switchboards. It comes equipped with load side lugs and is HACR rated for use with heating and cooling systems.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED21B060 |
| Series | ED2 |
| Amperage | 60A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC, 5kA @ 125VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Sentron Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs |
| Standards | CSA C22.2 No. 5, HACR Rated, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards are compatible with the Siemens ED21B060?
This bolt-on molded case circuit breaker is designed for use in Siemens P1, P2, and P3 panelboards, as well as legacy Sentron panelboards and Siemens switchboards.
Can the Siemens ED21B060 replace older I-T-E circuit breakers?
Yes. Siemens acquired I-T-E, and the ED21B060 is the direct, manufacturer-approved replacement for the legacy I-T-E ED21B060. It shares the same physical dimensions and ED2 frame design.
Is the ED21B060 rated for use in direct current (DC) systems?
Yes, this breaker is rated for 125VDC applications and provides a 5kA interrupting capacity (AIC) for DC systems, in addition to its standard 120VAC rating.
Is the Siemens ED21B060 HACR rated?
Yes, this breaker is HACR rated, meaning it is certified for use with heating, air conditioning, and refrigeration equipment that requires group motor protection.
Does the ED21B060 mount to standard DIN rails?
No. The ED21B060 is a bolt-on molded case circuit breaker designed specifically to bolt directly to the busbars inside compatible Siemens and Sentron panelboards. It is not designed for DIN rail mounting.
Are the trip settings on the ED21B060 adjustable?
No. This breaker features a fixed thermal-magnetic trip unit. Both the long-time (overload) and instantaneous (short-circuit) trip functions are factory-calibrated and cannot be adjusted in the field.
