Siemens ED63B035 Molded Case Circuit Breaker
- 35A
- 3 Pole
- Bolt-On
Siemens
ED63B035
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED63B035
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED63B035 - 35A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens ED63B035 - 35A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED63B035 |
| Series | ED6 |
| Amperage | 35A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lug (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Sold out
Quantity
Siemens ED63B035 - 35A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED63B035-R |
| Series | ED6 |
| Amperage | 35A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lug (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
40A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
30A 3 Pole Molded Case Circuit Breaker
Description
Part of the proven SENTRON family, this 35-amp bolt-on breaker delivers reliable circuit protection for commercial and industrial facilities. It integrates seamlessly into Siemens P1, P2, and P3 panelboards, as well as compatible motor control centers. The HACR-rated ED6 frame features a non-interchangeable thermal-magnetic trip unit with a 65kAIC interrupting capacity at 240VAC. It supports reverse feeding and accepts standard field-installable accessories for advanced control.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED63B035 |
| Series | ED6 |
| Amperage | 35A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lug (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhich Siemens panelboards are compatible with the ED63B035?
This bolt-on breaker is designed for use in Siemens P1, P2, and P3 panelboards, as well as compatible switchboards and motor control centers.
What wire sizes do the standard lugs on the ED63B035 accept?
The factory-installed lugs accept copper or aluminum conductors ranging from 10 AWG to 1/0 AWG.
Is the ED63B035 rated for direct current applications?
Yes, this breaker carries a 250VDC rating with an interrupting capacity of 30kA, making it suitable for specific DC control and distribution circuits.
How does the interrupting rating change between 480V and 600V systems?
The breaker provides 25kAIC protection on 480VAC systems and drops to 18kAIC when applied to 600VAC systems. Always verify the available fault current at your installation point.
What frame family does the ED63B035 belong to?
It is part of the Siemens Sentron series ED frame family. This specific model features a fixed thermal and fixed magnetic trip unit.
Does this breaker mount onto a standard DIN rail?
No, the ED63B035 requires a bolt-on connection. It is designed to bolt directly to the busbars of compatible Siemens distribution equipment rather than snapping onto a rail.
