Siemens EF3A003 Motor Circuit Protector
- 3A
- 3 Pole
- Bolt-On
Quantity
Siemens EF3A003 - 3A 3 Pole Motor Circuit Protector
Re-Certified
Quantity
Description
Engineered for precise motor branch circuit safety, the Siemens EF3A003 delivers adjustable magnetic-only tripping for 3A applications. Adjustments between 10 and 35 amps accommodate various motor starting characteristics without nuisance tripping. The E-frame protector mounts into Siemens and I-T-E panelboards or Motor Control Centers. Facilities can substitute this unit with the ED63A003 model. With a 14kAIC capacity at 600VAC, it provides reliable short-circuit defense.Specifications
| Brand | Siemens |
|---|---|
| Part Number | EF3A003-R |
| Series | EF |
| Amperage | 3A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Amperage Range | 10-35A |
|---|
| Frame Type | EF |
|---|---|
| Terminal Type | Lugs |
| For Use With | Motor Control Centers, Siemens / I-T-E Panelboards |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Motor Circuit Protector, Non-Interchangeable Trip |
