Siemens DTNF361R Heavy Duty Safety Switch
Quantity
Core Specs
See full specsSiemens DTNF361R Heavy Duty Safety Switch
New
Quantity
Description
Siemens DTNF361R Heavy Duty Safety Switch
Siemens Heavy Duty Safety Switch features a nema 3R, non-fusible type, single style, suitable for outdoor use. The safety switch has a current rating of 30 amps with a voltage rating of 600 v.It has an interrupt rating of 200kA@600V.
Specifications:
- Manufacturer: Siemens
- Cat. No: DTNF361R
- Alternate Part No: DTNF361R
- Product Type: Heavy Duty Safety Switch
- Frame Type: DTNF
- Series: VBII
- Type: DTNF
- Number Of Poles: 3
- Phase: 3
- Configuration: Single
- Voltage Rating: 600 V
- Amperage Rating: 30 A
- Interrupt Rating: 200kA@600V
- Size: 25 Inch H x 12 Inch W x 10 Inch D
- Mounting: Surface
- Material: Galvanized Steel
- Approval: UL
- Authentic Siemens Product
Specifications
| Amperage | 30 A |
|---|---|
| Voltage | 600 V |
| Phase | 3 |
| Configuration | Single |
| Poles | 3 |
|---|---|
| Interrupting Rating | 200KA@600V |
| Mounting Type | Surface |
|---|---|
| Frame Type | DTNF |
| Length (in) | 10 |
| Width (in) | 12 |
| Height (in) | 25 |
| Approval | UL |
|---|---|
| Body Material | Galvanized Steel |
| Series | VBII |
|---|---|
| Brand | Siemens |
| MPN | DTNF361R |
| UPC | 783643454231 |
