Siemens JD62F400 Circuit Breaker
- 400
- 2 Pole
Quantity
Siemens JD62F400 2 Pole Circuit Breaker
New
Quantity
Description
Siemens JD62F400 2 Pole Circuit Breaker
Siemens 2 pole circuit breaker features a thermal magnetic molded case for extra protection. The circuit breaker has a current rating of 400 amps with a voltage rating of 600 v. It has an interrupt rating of 35kAIC@480V.
Specifications:
Manufacturer: Siemens
Cat. No: JD62F400
Alternate Part No: JD62F400
Product Type: Circuit Breaker
Trip Unit Type: Interchangeable
Frame Type: JD
Frame Size: JD
Frame: JD
Series: Sentron
Type: JD
Phase: 1
Pole: 2
Voltage Rating: 600 V
Amperage Rating: 400 A
Connection: Bolt-On
Functions: LI - Long-Time and Instantaneous
Interrupt Rating: 35kAIC@480V
Terminals: Load Side Lug
Size: 6.6 Inch H x 8.8 Inch W x 14.7 Inch D
Circuit Breaker Type: Breaker Frame
Authentic Siemens Product
Specifications
| Brand | Siemens |
|---|---|
| Part Number | JD62F400 |
| Series | Sentron |
| Amperage | 400 A |
| Poles | 2 |
| Voltage | 600 V |
| Phase | 1 |
| AIC Rating | 35kAIC@480V |
| Frame Type | JD |
|---|---|
| Terminal Type | Load side lug |
| Trip Technology | Thermal Magnetic |
|---|
Product FAQs
5 answersWhat trip unit is required for the JD62F400 breaker frame?
The JD62F400 is an interchangeable breaker frame that requires a separate Sentron JD-frame thermal-magnetic trip unit to operate. For a 400A 2-pole configuration, use the JD62T400 trip unit.
Which wire lugs are compatible with this JD frame breaker?
The JD62F400 frame accepts standard Siemens lugs, including the TA2J6500 for aluminum or copper conductors and the TC2J6500 or TC1J6600 for copper-only applications. Lugs must be ordered separately for frame-only models.
Is the JD62F400 rated for direct current (DC) systems?
Yes, in addition to its 600V AC rating, this 2-pole breaker frame is rated for use in DC applications up to 250V DC.
What is the physical footprint of this 2-pole breaker frame?
The JD62F400 is built on a 3-pole width chassis. It will occupy the same physical space as a standard 3-pole JD frame circuit breaker when installed in a panelboard or enclosure.
How does the JD62F400 differ from the JD62B400 catalog number?
The JD62F400 includes the breaker frame only. The JD62B400 is a complete, unassembled breaker package that includes the JD62F400 frame, the JD62T400 trip unit, and standard line and load lugs.
