Siemens JL3B400 Molded Case Circuit Breaker
- 400A
- 3 Pole
- Bolt-On
Siemens
JL3B400
Molded Case Circuit Breaker
Brand
Siemens
SKU
JL3B400
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens JL3B400 - 400A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
350A 3 Pole Molded Case Circuit Breaker
300A 3 Pole Molded Case Circuit Breaker
300A 3 Pole Molded Case Circuit Breaker
Description
A reliable solution for commercial facilities, the Siemens JL3B400 is a 400-amp, 3-pole molded case circuit breaker. It utilizes thermal-magnetic technology to deliver long-time and instantaneous protection. Designed for bolt-on installation, this breaker is compatible with Siemens P4 and P5 panelboards, motor control centers, and older ITE FC-1 enclosures. For modern upgrades, this legacy J-Frame model is replaced by the JD63B400.Specifications
| Brand | Siemens |
|---|---|
| Part Number | JL3B400-R |
| Series | JL |
| Amperage | 400A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P4, P5 Panelboards, Switchboards, Motor Control Centers, Legacy ITE FC-1 Panelboards |
| Wire Gauge | 3/0 AWG - 500 kcmil |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | UL 489, CSA C22.2 No. 5, NEMA AB-1 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Interchangeable Trip Unit, Trip-Free Mechanism |
Product FAQs
5 answersWhat enclosures and panelboards are approved for the JL3B400?
This bolt-on breaker is approved for use in Siemens P4 and P5 panelboards, switchboards, and motor control centers. It is also backwards compatible with legacy ITE FC-1 panelboards.
How does the trip adjustability work on this J-frame breaker?
The JL3B400 features a thermal-magnetic trip unit with non-interchangeable elements. The thermal long-time protection is fixed at 400A, while the instantaneous magnetic trip dial is adjustable to help coordinate fault clearing times with downstream protective devices.
What are the acceptable wire sizes for the standard lugs?
The installed factory lugs accept copper or aluminum conductors ranging from 3/0 AWG up to 500 kcmil. Always ensure proper torque specifications are applied during termination.
Can the JL3B400 be applied in direct current networks?
Yes, this breaker carries a DC rating for systems up to 250VDC. In these specific applications, the interrupting capacity is tested and rated at 30kA.
Will the Siemens JL3B400 directly replace an original ITE branded unit?
Yes. Since Siemens acquired ITE, they continued manufacturing this legacy J-frame profile. The modern Siemens JL3B400 is an exact physical and electrical drop-in replacement for the older ITE JL3B400 model without requiring modifications to the busway.
