Siemens JXD62B200 Molded Case Circuit Breaker
- 200A
- 2 Pole
- Unit Mount
Siemens
JXD62B200
Molded Case Circuit Breaker
Brand
Siemens
SKU
JXD62B200
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens JXD62B200 - 200A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens JXD62B200 - 200A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | JXD62B200 |
| Series | JXD6 |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | JXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 3/0 AWG - 500 kcmil |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Sold out
Quantity
Siemens JXD62B200 - 200A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | JXD62B200-R |
| Series | JXD6 |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | JXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 3/0 AWG - 500 kcmil |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
250A 2 Pole Molded Case Circuit Breaker
250A 2 Pole Molded Case Circuit Breaker
300A 2 Pole Molded Case Circuit Breaker
Description
Engineered for industrial environments, the Siemens JXD62B200 is a 2-pole, 200A molded case circuit breaker from the Sentron series. It provides reliable long-time and instantaneous (LI) protection. This unit mount MCCB installs into Siemens Sentron panelboards, switchboards, and motor control centers. It requires separate lug kits for wire termination, accepting 3/0 AWG to 500 kcmil conductors.Specifications
| Brand | Siemens |
|---|---|
| Part Number | JXD62B200 |
| Series | JXD6 |
| Amperage | 200A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | JXD |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Sentron Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 3/0 AWG - 500 kcmil |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CE, CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
5 answersCan the Siemens JXD62B200 replace older I-T-E circuit breakers?
Yes, Siemens acquired I-T-E and continues to manufacture the Sentron series. The JXD62B200 is a direct replacement for legacy I-T-E breakers with the exact same catalog number.
Is the JXD62B200 suitable for reverse feed applications?
Yes. Because the JXD62B200 features a factory-installed, non-interchangeable trip unit, it is not restricted by Line and Load markings and can be safely reverse fed.
What does the adjustable magnetic trip on this breaker do?
The adjustable magnetic trip allows you to set the instantaneous short-circuit pickup level. This provides customized protection coordination for your specific electrical system, while the thermal overload element remains fixed.
Is the JXD62B200 compatible with standard Siemens Sentron panelboards?
Yes, this JD-frame molded case circuit breaker is designed for unit mount installations in Siemens Sentron panelboards, as well as compatible switchboards and motor control centers.
What does the X in the JXD62B200 catalog number indicate?
The X designates that this breaker is built with a non-interchangeable trip unit. This means the thermal-magnetic trip mechanism is factory-sealed and cannot be swapped out or modified in the field.
