Siemens MP360 Miniature Circuit Breaker
- 60A
- 3 Pole
- Plug-On
Siemens
MP360
Miniature Circuit Breaker
Brand
Siemens
SKU
MP360
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens MP360 - 60A 3 Pole Miniature Circuit Breaker
New
Quantity
Similar Items
Description
Delivering robust thermal-magnetic protection, the MP360 handles demanding electrical loads. This three-pole, 60-amp component is built for mixed applications. It installs easily into Murray and Siemens load centers using a standard plug-on mount. This unit is frequently replaced by the Siemens Q360, ensuring continued support for existing panelboards. Featuring a 10kAIC rating at 240VAC, it provides essential defense against short circuits and carries an HACR certification for HVAC use.Specifications
| Brand | Siemens |
|---|---|
| Part Number | MP360 |
| Series | MP |
| Amperage | 60A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | MP |
|---|---|
| Terminal Type | Lugs |
| For Use With | Murray Load Centers, Siemens Load Centers |
| Wire Gauge | 8-2 AWG (Cu/Al) |
| Max Wire | 2 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2, HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip, HACR Rated |
Product FAQs
6 answersCan the MP360 be installed in a Siemens load center?
Yes, this breaker is compatible with both Murray and Siemens load centers that accept plug-on miniature circuit breakers.
Is there a difference between the Murray MP360 and the Siemens MP360?
No, they are the same component. Siemens acquired the Murray brand and continued producing the MP series breakers under the Siemens name.
What is the current Siemens equivalent for the MP360?
Siemens has transitioned the Murray MP line to the QP series. The direct, UL-listed replacement for the MP360 is the Siemens Q360.
What wire materials are acceptable for the MP360 lugs?
The terminals are rated for both copper (Cu) and aluminum (Al) conductors, accepting wire sizes from 8 AWG to 2 AWG.
Is the MP360 suitable for HVAC applications?
Yes, this breaker is HACR rated, meaning it is approved for use with heating, air conditioning, and refrigeration equipment.
Does this breaker utilize a common trip mechanism?
Yes, the MP360 features an internal common trip. An overcurrent condition on any single phase will trip all three poles simultaneously to safely open the circuit.
