Siemens P230 Molded Case Circuit Breaker
- 30A
- 2 Pole
- Bolt-On
Quantity
Siemens P230 - 30A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens P230 - 30A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | P230 |
| Series | P |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Screw/Clamp Terminal |
|---|---|
| For Use With | ITE / Siemens Pushmatic Load Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip |
Quantity
Siemens P230 - 30A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | P230-R |
| Series | P |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Screw/Clamp Terminal |
|---|---|
| For Use With | ITE / Siemens Pushmatic Load Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip |
Description
Designed to maintain older electrical infrastructure, the Siemens P230 is a 2-pole, 30A Pushmatic circuit breaker. It provides reliable overcurrent and short-circuit protection for both residential and commercial environments. The bolt-on configuration mounts into ITE, Siemens, Gould, and Bulldog Pushmatic load centers. It acts as an exact substitute for legacy P230 models, making it an essential component for facility managers servicing vintage panelboards.Specifications
| Brand | Siemens |
|---|---|
| Part Number | P230 |
| Series | P |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Screw/Clamp Terminal |
|---|---|
| For Use With | ITE / Siemens Pushmatic Load Centers |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Accessories | Load Side Lugs Included |
|---|---|
| Standards | UL 489, CSA C22.2 No. 5 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Common Trip |
Product FAQs
6 answersWhich load centers are compatible with the Siemens P230 circuit breaker?
The P230 is designed exclusively for Pushmatic load centers. Depending on the age of the installation, these panels may be branded as ITE, Bulldog, Gould, or Siemens. It will not fit in standard plug-on or modern bolt-on panelboards.
How is the P230 breaker installed in a panel?
This breaker utilizes a bolt-on connection. It fastens directly to the bus bar of a Pushmatic load center using screws, which provides a secure and vibration-resistant electrical connection.
How does the switching mechanism on a Pushmatic breaker operate?
Pushmatic breakers do not use a standard toggle switch. Instead, they feature a push-button mechanism. You press the button to engage the contacts and turn the circuit on, and press it again to disconnect power or reset a tripped breaker.
What are the common cross-reference part numbers for the Siemens P230?
Because the Pushmatic line has changed ownership over the decades, this 30-amp, 2-pole breaker can also be identified as ITE P230, Bulldog P230, or Gould P230. The aftermarket replacement manufactured by Connecticut Electric is part number UBIP230.
What applications are typical for a 30A, 240V Pushmatic breaker?
A 30-amp double-pole breaker is frequently installed to protect 240V residential and light commercial loads. Common applications include electric water heaters, clothes dryers, and small air conditioning condensers. Always verify the manufacturer nameplate on the equipment to ensure proper sizing.
How can I visually verify if the P230 has tripped?
Pushmatic breakers include a mechanical flag indicator. When a thermal-magnetic trip occurs, the push-button releases outward and a label reading OFF or TRIPPED becomes visible in the indicator window.
