Square D HDL36100SA - 100A 3 Pole Molded Case Circuit Breaker

Brand Square D
SKU HDL36100SA
4.0
Rated 4.0 out of 5 stars
1 Review
Square D HDL36100SA 3 Pole Circuit Breaker
Free Shipping Over $99

Square D HDL36100SA - 100A 3 Pole Molded Case Circuit Breaker

Brand Square D
SKU HDL36100SA
4.0
Rated 4.0 out of 5 stars
1 Review
Select Item Condition
Earn 1363 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more
Square D HDL36100SA 3 Pole Circuit Breaker

Square D HDL36100SA - 100A 3 Pole Molded Case Circuit Breaker

New

$1363.00 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Engineered for commercial and industrial applications, the Square D HDL36100SA is a 3-pole, 100A molded case circuit breaker from the PowerPacT H-Frame family. It provides dependable thermal-magnetic (LI) protection for industrial control panels, enclosures, and switchboards. This unit features a factory-installed 120VAC shunt trip, allowing for remote tripping capabilities. Rated at 25kAIC at 240VAC and 14kAIC at 600VAC, it serves as a retrofit for legacy FAL361001021 breakers.

Specifications

Brand Square D
Series HDL
Part Number HDL36100SA
Amperage 100A
Voltage 240VAC, 480VAC, 600VAC, 250VDC
Poles 3
Phase 3
AIC Rating 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC, 20kA @ 250VDC
Mounting Style Unit Mount
Terminal Type Lugs
For Use With Industrial Control Panels, Switchboards, Enclosures
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 14-3/0 AWG (Al/Cu)
Max Wire 3/0 AWG
Min Wire 14 AWG
Available Options Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Padlock Attachment
Accessories Lugs, Shunt Trip
Standards CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489
Approval CE, CSA, HACR, IEC, NOM, UL
Temp Rating -25C to 70C
Construction Features HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip
