Schneider Electric HDL36100SA Circuit Breaker
- 100
- 3 Pole
- Unit
Schneider Electric
HDL36100SA
Circuit Breaker
Brand
Schneider Electric
SKU
HDL36100SA
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Schneider Electric HDL36100SA 3 Pole Circuit Breaker
New
Quantity
Quantity
Schneider Electric HDL36100SA 3 Pole Circuit Breaker
New
Quantity
| Brand | Schneider Electric |
|---|---|
| Part Number | HDL36100SA |
| Series | PowerPacT H |
| Amperage | 100 A |
| Poles | 3 |
| Mounting Style | Unit |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 18kAIC at 480VAC |
| Frame Type | HDL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Industrial Control Panels, Switchboards, Enclosures |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | AWG 3/0 |
| Min Wire | AWG 14 |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Padlock Attachment |
|---|---|
| Accessories | Lugs, Shunt Trip |
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25 to 70 °C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Sold out
Quantity
Schneider Electric HDL36100SA 3 Pole Circuit Breaker
Re-Certified
Quantity
| Brand | Schneider Electric |
|---|---|
| Series | PowerPacT H |
| Amperage | 100 A |
| Poles | 3 |
| Mounting Style | Unit |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 18kAIC at 480VAC |
| Frame Type | HDL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Industrial Control Panels, Switchboards, Enclosures |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | AWG 3/0 |
| Min Wire | AWG 14 |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Padlock Attachment |
|---|---|
| Accessories | Lugs, Shunt Trip |
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25 to 70 °C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Similar Items
80A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
125A 3 Pole Molded Case Circuit Breaker
Description
Schneider Electric HDL36100SA 3 Pole Circuit Breaker
The Schneider Electric HDL36100SA is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 100 Amps and a voltage rating of 600VAC. It has an interrupting rating of 18kAIC at 480VAC. The HDL36100SA has a feed-thru connection type and includes long time and instantaneous trip functions.
Specifications
| Brand | Schneider Electric |
|---|---|
| Part Number | HDL36100SA |
| Series | PowerPacT H |
| Amperage | 100 A |
| Poles | 3 |
| Mounting Style | Unit |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 18kAIC at 480VAC |
| Frame Type | HDL |
|---|---|
| Terminal Type | Lugs |
| For Use With | Industrial Control Panels, Switchboards, Enclosures |
| Wire Gauge | 14-3/0 AWG (Al/Cu) |
| Max Wire | AWG 3/0 |
| Min Wire | AWG 14 |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Padlock Attachment |
|---|---|
| Accessories | Lugs, Shunt Trip |
| Standards | RoHS, REACh, HACR |
| Approval | UL, CSA, CE, NEMA, NOM, IEC |
| Temp Rating | -25 to 70 °C |
| Construction Features | HACR Rated, Current Limiting, Visual Trip Indicator, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
7 answersWhat does the "SA" suffix mean in the HDL36100SA catalog number?
The "SA" suffix indicates that this breaker comes with a factory-installed 110-130 VAC shunt trip. This accessory allows the breaker to be tripped remotely using a control voltage signal.
What does the "D" in the HDL36100SA part number signify?
The "D" designates the interrupting rating tier within the Square D PowerPacT H-frame family. For this specific breaker, the D-rating provides an 18 kA interrupting capacity at 480 VAC.
Is the HDL36100SA compatible with Square D I-Line panelboards?
No, the HDL36100SA is a unit-mount (feed-thru) circuit breaker designed to be hardwired in industrial control panels, switchboards, or standalone enclosures. It does not have the plug-on jaw connections required for I-Line panelboards.
Can the HDL36100SA be reverse fed?
Yes, standard thermal-magnetic PowerPacT H-frame breakers like the HDL36100SA are suitable for reverse feeding. This allows you to connect the incoming line power to either the top or bottom lugs without affecting the breaker's protective functions.
Can I field-install a shunt trip on a standard HDL36100 instead of buying the HDL36100SA?
Yes, PowerPacT H-frame breakers support field-installable accessories. However, purchasing the HDL36100SA provides the 110-130 VAC shunt trip already factory-installed, which saves assembly time and ensures proper factory testing.
What type of trip unit is equipped on the HDL36100SA?
This breaker features a fixed thermal-magnetic trip unit with Long-Time (L) and Instantaneous (I) protection. Both the thermal overload and magnetic short-circuit trip thresholds are factory-fixed and cannot be adjusted.
Does the HDL36100SA include a Visi-Trip indicator?
Yes, Square D PowerPacT H-frame breakers feature a Visi-Trip indicator. When the breaker trips, the handle snaps to a center position and a highly visible red indicator appears, making it easy to identify a tripped breaker in a crowded panel.
