ABB / General Electric TQD32175ST1 Molded Case Circuit Breaker
- 175A
- 3 Pole
- Unit Mount
Quantity
ABB / General Electric TQD32175ST1 - 175A 3 Pole Molded Case Circuit Breaker
New
Quantity
Description
Engineered for commercial applications, the GE TQD32175ST1 is a 3-pole, 175-amp molded case circuit breaker from the Q-Line family. It provides thermal-magnetic protection with a 10kAIC rating at 240VAC and includes a factory-installed shunt trip for remote tripping. This unit mount breaker is designed for integration into GE A-Series and Spectra Series panelboards. For facilities upgrading legacy infrastructure, it can be replaced by the ABB Tmax XT3 series using a retrofit kit.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | TQD32175ST1 |
| Series | TQD |
| Amperage | 175A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 120VAC, 240VAC, 120/240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 120VAC, 10kA @ 240VAC, 10kA @ 120/240VAC |
| Frame Type | TQD |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE A-Series Panelboards, GE Spectra Series Panelboards |
| Wire Gauge | 4 AWG - 300 kcmil (Cu/Al) |
| Max Wire | 300 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Shunt Trip (Factory Installed), Load Side Lugs (TCAL25) |
| Standards | CSA C22.2 No. 5, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip, Non-Interchangeable Trip, Reverse Feed |
Product FAQs
6 answersWhich panelboards are compatible with the TQD32175ST1 circuit breaker?
This bolt-on breaker is engineered for integration into commercial GE A-Series and Spectra Series panelboards. It is not compatible with standard residential load centers.
What does the ST1 suffix indicate on the TQD32175ST1 catalog number?
The ST1 suffix designates that this breaker includes a factory-installed shunt trip mechanism. This allows the breaker to be tripped remotely via an external control signal.
Are the thermal and magnetic trip points adjustable on this breaker?
No, this breaker features a fixed thermal and fixed magnetic trip unit. The long-time and instantaneous (LI) trip functions are factory set and cannot be modified in the field.
Why is this breaker branded as both ABB and General Electric?
ABB acquired GE Industrial Solutions. As a result, Q-Line breakers like the TQD32175ST1 may carry either the GE or ABB logo depending on the manufacturing date, but they are physically and electrically identical.
Is there a modern replacement for the TQD32175ST1 when upgrading legacy infrastructure?
Yes, if you are upgrading older panels, this TQD frame breaker can be replaced by the newer ABB Tmax XT3 series using a specific ABB retrofit kit.
Does the TQD32175ST1 provide ground fault or arc fault protection?
No, this is a standard thermal-magnetic breaker providing overload (long-time) and short-circuit (instantaneous) protection. It does not include GFCI or AFCI capabilities.
