Eaton / Westinghouse EHB2030 Molded Case Circuit Breaker
- 30A
- 2 Pole
- Bolt-On
Quantity
Eaton / Westinghouse EHB2030 - 30A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Rated for 14kAIC at 480Y/277VAC, the Eaton EHB2030 is a 2-pole, 30A molded case circuit breaker engineered for demanding commercial environments. It utilizes fixed thermal-magnetic trip units to safeguard against overloads. This breaker is specifically designed to mount into legacy Westinghouse NEHB panelboards. As an exact-fit replacement, it restores older distribution systems and is officially replaced by the EHD2030.Specifications
| Brand | Eaton / Westinghouse |
|---|---|
| Part Number | EHB2030-R |
| Series | EHB |
| Amperage | 30A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480Y/277VAC, 10kA @ 250VDC |
| Frame Type | EHB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Westinghouse NEHB Panelboards |
| Wire Gauge | 14-10 AWG (Al/Cu) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Non-Interchangeable Trip |
Product FAQs
5 answersWhich panelboards are compatible with the EHB2030 circuit breaker?
The EHB2030 is specifically designed for installation in legacy Westinghouse and Eaton NEHB panelboards.
Is the EHB2030 obsolete, and what is the direct replacement?
Yes, the EHB series is a legacy product. The Eaton EHD2030 serves as the official exact-fit replacement for the EHB2030.
Can the EHB2030 be used in DC power systems?
Yes, this breaker is rated for DC applications, providing a 10kA interrupting capacity at 250VDC.
What wire sizes are accepted by the EHB2030 terminals?
The included load side lugs accept aluminum or copper conductors ranging from 14 AWG to 10 AWG.
What type of trip unit does the EHB2030 utilize?
It features a non-interchangeable, thermal-magnetic trip unit with fixed long-time and instantaneous trip functions to protect against overloads and short circuits.
