Eaton / Cutler-Hammer LA3225 Molded Case Circuit Breaker
- 225A
- 3 Pole
- Bolt-On
Quantity
Eaton / Cutler-Hammer LA3225 - 225A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Description
Designed for legacy industrial systems, the Eaton LA3225 delivers robust 225A overcurrent protection. This 3-pole L-Frame breaker is engineered to mount into vintage Westinghouse PRL4 panelboards, switchboards, and motor control centers. While it serves as a functional substitute for HLD3225 and KD3225 models, it is replaced by the newer Series C LD3225. The unit provides a 30kAIC rating at 480VAC and includes an interchangeable thermal-magnetic trip with adjustable magnetic settings.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | LA3225-R |
| Series | LA |
| Amperage | 225A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 42kA @ 240VAC, 30kA @ 480VAC, 22kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Westinghouse PRL4 Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 4 AWG-350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Lugs |
| Standards | NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Interchangeable Trip Unit |
Product FAQs
6 answersWhat equipment is the LA3225 circuit breaker designed to fit?
This bolt-on L-frame breaker is compatible with legacy Westinghouse PRL4 panelboards, as well as various switchboards and motor control centers designed for L-frame dimensions.
How is the trip unit configured on this breaker?
The LA3225 features a thermal-magnetic trip unit with a fixed thermal element for overload protection and an adjustable magnetic element for short-circuit protection. The magnetic pickup can be adjusted using the dials on the face of the breaker to coordinate with downstream devices.
What type of conductors can be terminated on the LA3225 lugs?
The standard mechanical lugs on this breaker are dual-rated for both aluminum and copper conductors, accepting wire sizes from 4 AWG up to 350 kcmil. Always apply an appropriate oxide inhibitor when terminating aluminum conductors.
Is the LA3225 still actively manufactured?
No, the original Westinghouse LA3225 is obsolete. Eaton acquired the Westinghouse distribution equipment line and Cutler-Hammer, so this breaker may carry any of those three brand names depending on its exact date of manufacture.
How does the interrupting capacity of the LA3225 change between AC and DC systems?
The LA3225 provides up to 42kA of interrupting capacity at 240VAC, but when applied to DC systems, it is rated for a maximum of 250VDC with a 10kA interrupting capacity. Always verify the available fault current of your specific application before installation.
What safety considerations apply when adjusting the magnetic trip settings?
Adjustments to the magnetic trip dials should only be performed by a qualified electrician or engineer based on a proper coordination study. Incorrect settings can lead to nuisance tripping or failure to clear a fault, compromising system safety.
