Eaton / Cutler-HammerCHFAFGF115
Eaton / Cutler-Hammer CHFAFGF115PN Dual Function Miniature Circuit Breaker
- 15A
- 1 Pole
- Plug-On
Eaton / Cutler-Hammer
CHFAFGF115PN
Dual Function Miniature Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
CHFAFGF115PN
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer CHFAFGF115PN - 15A Dual Function Miniature Circuit Breaker
New
Quantity
Similar Items
Eaton / Cutler-HammerCHFAFGF120PN
20A Dual Function Miniature Circuit Breaker
Eaton / Cutler-HammerCHFN115DF
15A Dual Function Miniature Circuit Breaker
Description
Delivering comprehensive electrical safety, this 15A dual-function breaker combines Combination Type AFCI and GFCI protection. Engineered for residential applications, it meets NEC codes requiring dual protection. This unit installs into Eaton CH plug-on neutral load centers, eliminating the pigtail connection. Note that this model is officially replaced by the newer CHFP115DF. Rated 10kAIC at 120VAC, it features a trip flag and LED diagnostic indicator to reduce troubleshooting time.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | CHFAFGF115PN |
| Series | CHF |
| Amperage | 15A |
| Poles | 1 |
| Mounting Style | Plug-On |
| Voltage | 120VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120VAC |
| Frame Type | CH |
|---|---|
| Terminal Type | Box Lugs |
| For Use With | Eaton CH Plug-On Neutral Load Centers |
| Wire Gauge | (1) 14-8 AWG (Cu/Al) or (2) 14-10 AWG (Cu/Al) |
| Max Wire | 8 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LIG |
| Trip Function | Long-Time, Instantaneous, Ground Fault |
| Trip Adjustability | Fixed |
| Special Classification | Dual Function (AFCI/GFCI) |
|---|---|
| Available Options | Padlock Attachment |
| Accessories | Trip Flag |
| Standards | HACR Rated, UL 1699, UL 489, UL 943 |
| Approval | UL, UL 1699, UL 489, UL 943 |
| Temp Rating | 40C |
| Construction Features | HACR Rated, SWD Rated, Visual Trip Indicator |
Product FAQs
8 answersWhat type of load center is required for the CHFAFGF115PN?
This breaker requires an Eaton CH series Plug-On Neutral (PON) load center. It will not fit in standard pigtail style panels or BR series load centers.
Does this breaker require a pigtail wire to connect to the neutral bar?
No. The CHFAFGF115PN features a Plug-On Neutral design, meaning it connects directly to the neutral bar in a compatible Eaton CH PON panel without the need for a pigtail wire.
What does Dual Function mean on this Eaton breaker?
Dual function indicates that the breaker provides both Arc Fault Circuit Interrupter (AFCI) and 5mA Ground Fault Circuit Interrupter (GFCI) personnel protection in a single device.
How can I tell if the CHFAFGF115PN has tripped?
The CHF series features a mechanical trip flag that visually differentiates a tripped breaker from one that has been manually turned off. It also includes a diagnostic LED that blinks to indicate the specific cause of the trip.
What is the pigtail equivalent if I do not have a Plug-On Neutral panel?
If your Eaton CH load center does not support Plug-On Neutral breakers, you will need the standard pigtail version, catalog number CHFAFGF115 or CHFN115DF.
What wire sizes are compatible with the box lugs on this breaker?
The terminals accept one 14 to 8 AWG copper or aluminum wire, or two 14 to 10 AWG copper or aluminum wires.
Can I install this 3/4-inch breaker in a Square D or Siemens panel?
No. Eaton CH series breakers have a proprietary 3/4-inch width and mounting clip designed exclusively for Eaton Cutler-Hammer CH load centers.
What does a solid red LED mean on my Eaton CHF dual function breaker?
According to Eaton, a constantly illuminated red LED that does not blink is a known cosmetic firmware issue and does not indicate a safety concern or a loss of AFCI or GFCI protection. The diagnostic blink codes for actual trip events will still function normally.
