Federal Pacific NEF214090 Molded Case Circuit Breaker
- 90A
- 1 Pole
- Bolt-On
Federal Pacific
NEF214090
Molded Case Circuit Breaker
Brand
Federal Pacific
SKU
NEF214090
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Federal Pacific NEF214090 - 90A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
80A 1 Pole Molded Case Circuit Breaker
70A 1 Pole Molded Case Circuit Breaker
30A 1 Pole Molded Case Circuit Breaker
Description
Serving as a crucial component for industrial power systems, this 90A molded case circuit breaker delivers dependable long-time and instantaneous trip functions. The N-frame design accommodates 4-1/0 AWG wire via standard lug terminals. Designed specifically for legacy Federal Pacific panelboards, it offers an exact fit for aging infrastructure. Facility managers can utilize this unit to maintain existing enclosures, or substitute it with the UBIF090N equivalent.Specifications
| Brand | Federal Pacific |
|---|---|
| Part Number | NEF214090 |
| Series | NEF |
| Amperage | 90A |
| Poles | 1 |
| Mounting Style | Bolt-On |
| Voltage | 120VAC, 277VAC, 125VDC |
| Phase | 1 |
| AIC Rating | 25kA @ 120VAC, 14kA @ 277VAC, 10kA @ 125VDC |
| Frame Type | NEF |
|---|---|
| Terminal Type | Lugs |
| For Use With | Federal Pacific Panelboards |
| Wire Gauge | 4-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 4 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Non-Interchangeable Trip, Reverse Feed, Vibration Tested, HACR Rated |
Product FAQs
6 answersWhich panelboards accept the Federal Pacific NEF214090 circuit breaker?
This N-frame breaker is specifically engineered to mount into legacy Federal Pacific commercial and industrial panelboards. It is not compatible with residential Stab-Lok load centers.
Is there a modern replacement available for the NEF214090?
Yes, because original Federal Pacific breakers are legacy components, facility managers often use the UBIF090N as a verified aftermarket substitute. It is designed to fit the exact same N-frame enclosures.
What wire gauge is required for installing the NEF214090?
The factory-installed load-side lugs accept wire sizes from 4 AWG up to 1/0 AWG. Ensure your conductor sizing aligns with the 90-amp rating and local electrical codes for your specific application.
How does the interrupting capacity of the NEF214090 change across different voltage systems?
The breaker provides a 14kAIC rating for standard 277VAC commercial lighting circuits, but the interrupting capacity increases to 25kAIC when installed in 120VAC applications. It also supports 125VDC systems with a 10kAIC rating.
How is the NEF214090 secured to the panelboard bus?
This model utilizes a bolt-on connection rather than a plug-on design. This ensures a highly secure, vibration-resistant contact suitable for commercial and industrial environments.
What type of trip unit is installed in the NEF214090?
It features a non-interchangeable thermal-magnetic trip unit with fixed long-time and instantaneous (LI) functions, providing standard overload and short-circuit protection.
