Siemens / ITE EE3M015 Molded Case Circuit Breaker
- 15A
- 3 Pole
- Unit Mount
Siemens / ITE
EE3M015
Molded Case Circuit Breaker
Brand
Siemens / ITE
SKU
EE3M015
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens / ITE EE3M015 - 15A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
15A 3 Pole Molded Case Circuit Breaker
15A 3 Pole Molded Case Circuit Breaker
15A 3 Pole Molded Case Circuit Breaker
Description
Engineered for high-temperature applications, the EE3M015 features a specialized 50°C ambient calibration originally designated by the 'M' suffix. This 3-pole, 15A unit mount breaker provides reliable thermal-magnetic protection for industrial and marine systems. It mounts into older ITE and Siemens P1, P2, and CDP panelboards without adapters. This component serves as an exact physical match for aging infrastructure. When standard 40°C breakers fall short, this 10kAIC rated unit delivers.Specifications
| Brand | Siemens / ITE |
|---|---|
| Part Number | EE3M015-R |
| Series | EE |
| Amperage | 15A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | ITE / Siemens Panelboards (e.g., P1, P2, CDP) |
| Wire Gauge | 14-10 AWG (Cu/Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Lugs (Factory Included) |
| Standards | UL 489, NEMA AB-1 |
| Approval | UL |
| Temp Rating | 50C |
| Construction Features | 50C Ambient Calibration, Non-Interchangeable Trip |
Product FAQs
6 answersWhich panelboards accept the EE3M015 circuit breaker?
This E-frame breaker is designed for installation in legacy ITE and Siemens panelboards, specifically fitting models like the P1, P2, and CDP series.
What type of wire can be used with the load side lugs on the EE3M015?
The load side terminals are rated for both copper (Cu) and aluminum (Al) conductors, accepting wire sizes from 14 AWG to 10 AWG.
Are the thermal and magnetic trip elements adjustable on this breaker?
No. It is equipped with a non-interchangeable thermal-magnetic trip unit featuring fixed long-time and instantaneous (LI) trip functions, meaning the trip curve cannot be modified in the field.
Does this breaker plug into the busbar or bolt on?
The EE3M015 requires a bolt-on connection. It must be mechanically fastened to the panelboard bus, which provides a secure and reliable connection for industrial and commercial applications.
Is the EE3M015-R the same as the EE3M015?
Yes, EE3M015-R is the alternate catalog number and variant SKU for the standard EE3M015 circuit breaker. They represent the exact same 15-amp, 3-pole E-frame breaker.
What is the ambient temperature rating for the EE3M015?
This molded case circuit breaker is calibrated for use in environments with a maximum ambient temperature of 50 degrees Celsius.
