Eaton / Cutler-Hammer EH3035 Molded Case Circuit Breaker
- 35A
- 3 Pole
- Bolt-On
Eaton / Cutler-Hammer
EH3035
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
EH3035
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer EH3035 - 35A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
20A 3 Pole Molded Case Circuit Breaker
15A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial and industrial applications, the EH3035 provides robust overcurrent protection for 3-phase systems. This 35-amp molded case circuit breaker features a fixed thermal-magnetic trip unit for standard long-time and instantaneous response. Designed as a bolt-on component, it mounts into Eaton Pow-R-Line panelboards, switchboards, and motor control centers. For modern upgrades, this legacy E-Frame unit is replaced by the EHD3035 model.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EH3035 |
| Series | EH |
| Amperage | 35A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Pow-R-Line Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-2 AWG (Al/Cu) |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | UL 489, CSA C22.2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, Non-Interchangeable Trip |
Product FAQs
5 answersWhat panelboards are compatible with the EH3035 circuit breaker?
This bolt-on breaker mounts directly into Eaton Pow-R-Line panelboards, switchboards, and motor control centers. It also serves as a direct fit for legacy Westinghouse E-frame distribution equipment.
Is the EH3035 a direct replacement for older Westinghouse E-frame breakers?
Yes. Eaton acquired the Westinghouse distribution equipment line, so the Eaton EH3035 directly replaces legacy Westinghouse breakers sharing the same catalog number and E-frame footprint.
What is the modern replacement for the legacy EH3035 breaker?
For modern panel upgrades, the legacy EH3035 is typically replaced by the Eaton Series C EHD3035 molded case circuit breaker.
What wire size and material does the EH3035 accept?
The factory-installed lugs on the EH3035 accept 14 AWG to 2 AWG wire. The terminals are rated for both aluminum and copper (Al/Cu) conductors.
Can the EH3035 be used in DC electrical systems?
Yes, in addition to its AC ratings, the EH3035 is rated for DC applications with an interrupting capacity of 10kA at 250VDC.
