Eaton EGE3060FFG 3 Pole Circuit Breaker

Brand Eaton
SKU EGE3060FFG
(1 Reviews)

Eaton EGE3060FFG 3 Pole Circuit Breaker

Brand Eaton
SKU EGE3060FFG
(1 Reviews)
Select Item Condition

Quantity
Buy Now. Pay Later with Shop Pay.
Earn 665 SuperPoints
Add to Favorites Added to Favorites
Hassle-free returns
Fast and reliable shipping
Free shipping over $99

Eaton EGE3060FFG 3 Pole Circuit Breaker

New

$665.19 In stock

Quantity

Description

Eaton EGE3060FFG 3 Pole Circuit Breaker

The Eaton EGE3060FFG is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 60 Amps and a voltage rating of 600V. It has an interrupting rating of 25kAIC at 480VAC, 35kAIC at 240VAC, 18kAIC at 600Y/347VAC. The EGE3060FFG has a free standing mounting type and includes long time and instantaneous trip functions.

Specifications

Brand Eaton
Series G
Amperage 60
Voltage 600Y/347 VAC
Poles 3
Phase 3
Mounting Type Free Standing
Approval CSA, IEC, UL
Interrupting Rating 18 kAIC at 600Y/347 Vac, 35 kAIC at 240 Vac, 25 kAIC at 480 Vac
Frame Type EG
Connection Type Line and Load
Protection Thermal Magnetic
Functions Long Time and Instantaneous
Terminal Connection Line and load
Length (in) 2.99
Width (in) 3
Height (in) 5.5
For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
Temperature Rating 40 deg C
Circuit Breaker Type EG
Actuator Type Toggle
Max Wire Size 1/0 AWG
Min Wire Size 14 AWG
Mpn EGE3060FFG
Upc 782114876770
Gtin 782114876770
