ABB / General Electric FCN36TE030R Molded Case Circuit Breaker
- 30A
- 3 Pole
- Unit Mount
ABB / General Electric
FCN36TE030R
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
FCN36TE030R
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric FCN36TE030R - 30A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
ABB / General ElectricFBN36TE030RV
30A 3 Pole Molded Case Circuit Breaker
ABB / General ElectricFBH36TE030RV
30A 3 Pole Molded Case Circuit Breaker
Description
Built for commercial power systems, the GE FCN36TE030R is a 3-pole, 30A circuit breaker from the Record Plus FCN series. It utilizes fixed thermal-magnetic trip elements to deliver dependable LI protection. Designed as a unit mount breaker, it integrates into GE switchboards and motor control centers. It can also be adapted for Spectra panelboards. This configuration does not include terminal lugs. Delivering 65kAIC at 480V, this HACR-rated breaker features current-limiting technology.Specifications
| Brand | ABB / General Electric |
|---|---|
| Series | FCN |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600Y/347VAC, 250VDC, 500VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 40kA @ 250VDC, 40kA @ 500VDC |
| Frame Type | FC100 |
|---|---|
| Terminal Type | Lugs |
| For Use With | GE Switchboards, Motor Control Centers, Enclosures, GE Spectra Panelboards (with retrofit kit) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Lug Kits |
|---|---|
| Accessories | Lugs Not Included |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB-1, UL 489 |
| Approval | CCC, CE, CSA, KEMA, Lloyd's, UL |
| Temp Rating | 40C |
| Construction Features | Current Limiting, HACR Rated, Reverse Feed |
Product FAQs
6 answersWhich panelboards and enclosures are compatible with the FCN36TE030R?
This breaker is designed for use in GE switchboards, motor control centers, and standalone enclosures. It can also be installed in GE Spectra panelboards when using the appropriate retrofit kit.
Why might this breaker arrive with ABB branding instead of General Electric?
ABB acquired GE Industrial Solutions in 2018. Depending on the manufacturing date, the FCN36TE030R may feature either ABB or GE branding, but the physical dimensions, mounting, and electrical specifications remain identical.
Can the FCN36TE030R be used in direct current (DC) systems?
Yes, this breaker is rated for DC applications. It provides a 40kA interrupting capacity at both 250VDC and 500VDC.
Are the thermal and magnetic trip settings adjustable on this breaker?
No, the FCN36TE030R features a fixed thermal and fixed magnetic trip unit. The long-time and instantaneous trip functions are factory set and cannot be adjusted in the field.
What does the FC100 frame designation mean for this 30A breaker?
The FC100 frame indicates the physical size and maximum amperage capacity of this specific Record Plus breaker line. While this specific model is rated for 30A, it shares the same physical dimensions as other FC-frame breakers rated up to 100A.
How is the FCN36TE030R mounted inside a panel?
This is a unit mount, bolt-on circuit breaker. It secures directly to the panel bus or mounting pan using bolted connections rather than snapping or plugging into place.
