Siemens Q360 Miniature Circuit Breaker
- 60A
- 3 Pole
- Plug-On
Siemens
Q360
Miniature Circuit Breaker
Brand
Siemens
SKU
Q360
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens Q360 - 60A 3 Pole Miniature Circuit Breaker
New
Quantity
Quantity
Siemens Q360 - 60A 3 Pole Miniature Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | Q360 |
| Series | QP |
| Amperage | 60A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Load Centers, Siemens Panelboards |
| Wire Gauge | 8-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip |
Sold out
Quantity
Siemens Q360 - 60A 3 Pole Miniature Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | Q360-R |
| Series | QP |
| Amperage | 60A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Load Centers, Siemens Panelboards |
| Wire Gauge | 8-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip |
Similar Items
60A 3 Pole Miniature Circuit Breaker
70A 3 Pole Miniature Circuit Breaker
70A 3 Pole Miniature Circuit Breaker
Description
Built for residential and commercial applications, the Siemens Q360 provides 60 amps of reliable thermal-magnetic protection. This 3-pole miniature circuit breaker installs into Siemens EQ, EQL, SEQ, and PL series load centers, as well as compatible panelboards. Rated for 10 kAIC at 240VAC, it features a common trip mechanism and is HACR rated for use with heating, air conditioning, and refrigeration equipment. It serves as a drop-in replacement for legacy Murray MP360 breakers.Specifications
| Brand | Siemens |
|---|---|
| Part Number | Q360 |
| Series | QP |
| Amperage | 60A |
| Poles | 3 |
| Mounting Style | Plug-On |
| Voltage | 240VAC |
| Phase | 3 |
| AIC Rating | 10kA @ 240VAC |
| Frame Type | Q |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens Load Centers, Siemens Panelboards |
| Wire Gauge | 8-4 AWG (Cu/Al) |
| Max Wire | 4 AWG |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Common Trip |
Product FAQs
5 answersWhat panelboards accept the Siemens Q360 circuit breaker?
This Type QP breaker is designed for use in Siemens 3-phase load centers and panelboards, including the EQ, EQL, SEQ, PL, and ES series. It requires three full 1-inch spaces for installation.
Can I use the Siemens Q360 to replace an older ITE or Gould breaker?
Yes. Siemens acquired ITE and Gould, maintaining the same catalog numbers. The current Q360 serves as a direct, UL-listed drop-in replacement for legacy ITE, Gould, and Murray MP360 3-pole breakers.
Is the Siemens Q360 suitable for commercial HVAC applications?
Yes, this breaker is HACR rated, meaning it is certified for use with heating, air conditioning, and refrigeration equipment.
What is the operating temperature rating for this breaker?
The Q360 features a standard 40 degrees Celsius (104 degrees Fahrenheit) ambient temperature rating for safe operation in typical panel environments.
Does the Q360 provide ground-fault or arc-fault protection?
No, the Q360 is a standard thermal-magnetic breaker. It provides overload and short-circuit protection but does not include GFCI or AFCI capabilities.
