Square D FAB36050 Circuit Breaker
- 50
- 3 Pole
- Bolt-On
Square D
FAB36050
Circuit Breaker
Brand
Square D
SKU
FAB36050
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Square D FAB36050 3 Pole Circuit Breaker
Re-Certified
Quantity
Similar Items
3 Pole Circuit Breaker
100A 3 Pole Molded Case Circuit Breaker
50A 3 Pole Molded Case Circuit Breaker
Description
Square D FAB36050 3 Pole Circuit Breaker
The Square D FAB36050 is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 50 Amps and a voltage rating of 600VAC. It has an interrupting rating of 25kAIC at 480V. The FAB36050 has an I-Line style bolt-on connection type and includes long time and instantaneous trip functions.
Specifications
| Brand | Square D |
|---|---|
| Series | FA |
| Amperage | 50 A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 600VAC |
| Phase | 3 |
| AIC Rating | 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | F |
|---|---|
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Visual Trip Indicator |
Product FAQs
7 answersWhich panelboards are compatible with the Square D FAB36050 circuit breaker?
The FAB36050 is designed for use in Square D I-Line panelboards and switchboards that accept legacy F-Frame bolt-on breakers.
Is the Square D FAB36050 still manufactured, or is there a modern replacement?
The FAB36050 is a legacy F-Frame breaker that has been discontinued by Schneider Electric. Its direct modern replacement is the PowerPacT B-Frame BDA36050, which provides the same 50A, 3-pole configuration for I-Line panels.
What is the difference between the FAB36050 and the FA36050?
Both are 50A, 3-pole F-Frame breakers for I-Line panels, but they feature different mounting connections. The FAB36050 utilizes a bolt-on I-Line connection, whereas the FA36050 uses a plug-on I-Line connection.
Can the FAB36050 be used in DC electrical systems?
Yes, in addition to its 600VAC rating, the FAB36050 is rated for use in 250VDC systems with an interrupting capacity of 10kAIC.
What wire sizes are accepted by the standard lugs on the FAB36050?
The standard mechanical lugs on this breaker accept copper or aluminum wire sizes ranging from 14 AWG to 1/0 AWG.
Are the trip settings on the FAB36050 adjustable?
No, this breaker features a thermal-magnetic trip unit with fixed thermal and fixed magnetic settings. The trip points cannot be adjusted in the field.
What type of protection does the FAB36050 provide?
It features a thermal-magnetic trip unit that provides long-time protection against overloads and instantaneous protection against short circuits, commonly referred to as LI protection.
