Eaton / Cutler-Hammer CAH2125 Molded Case Circuit Breaker
- 125A
- 2 Pole
- Unit Mount
Eaton / Cutler-Hammer
CAH2125
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
CAH2125
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer CAH2125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Eaton / Cutler-Hammer CAH2125 - 125A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | CAH2125 |
| Series | CAH |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton / Cutler-Hammer Metering Stacks, Group Metering, Type ECC Enclosures |
| Wire Gauge | #6 AWG - 350 kcmil |
| Max Wire | 350 kcmil |
| Min Wire | #6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5, NEMA AB 1 |
| Approval | CSA, UL |
| Temp Rating | 40°C |
| Construction Features | High Interrupting Capacity, Tenant Main, Feed-Thru Connection |
Sold out
Quantity
Eaton / Cutler-Hammer CAH2125 - 125A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | CAH2125-R |
| Series | CAH |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton / Cutler-Hammer Metering Stacks, Group Metering, Type ECC Enclosures |
| Wire Gauge | #6 AWG - 350 kcmil |
| Max Wire | 350 kcmil |
| Min Wire | #6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5, NEMA AB 1 |
| Approval | CSA, UL |
| Temp Rating | 40°C |
| Construction Features | High Interrupting Capacity, Tenant Main, Feed-Thru Connection |
Similar Items
175A 2 Pole Molded Case Circuit Breaker
200A 2 Pole Molded Case Circuit Breaker
225A 2 Pole Molded Case Circuit Breaker
Description
Built for multi-tenant power distribution, this 125-amp C-Frame device features fixed thermal-magnetic trip units. The CAH2125 provides reliable 22kAIC interrupting capacity at 240VAC for commercial and residential applications. It fits into Eaton group metering stacks and Type ECC enclosures, functioning effectively as a tenant main. With standard line and load lugs included, this unit mount breaker offers a dependable feed-thru connection for modern electrical upgrades.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | CAH2125 |
| Series | CAH |
| Amperage | 125A |
| Poles | 2 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton / Cutler-Hammer Metering Stacks, Group Metering, Type ECC Enclosures |
| Wire Gauge | #6 AWG - 350 kcmil |
| Max Wire | 350 kcmil |
| Min Wire | #6 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs Included |
| Standards | UL 489, CSA C22.2 No. 5, NEMA AB 1 |
| Approval | CSA, UL |
| Temp Rating | 40°C |
| Construction Features | High Interrupting Capacity, Tenant Main, Feed-Thru Connection |
Product FAQs
5 answersWhere is the CAH2125 typically installed?
This 125A C-Frame breaker is commonly used as a tenant main breaker in multi-tenant power distribution. It is compatible with Eaton and Cutler-Hammer group metering stacks as well as Type ECC enclosures.
Are line and load lugs included with the CAH2125?
Yes, standard line and load lugs are included. They accommodate wire sizes ranging from #6 AWG to 350 kcmil.
Does the CAH2125 plug onto a busbar?
No. The CAH2125 is a unit mount, feed-thru circuit breaker. It mounts directly into compatible metering stacks or ECC enclosures rather than snapping or plugging onto a standard panel busbar.
Are the trip settings on the CAH2125 adjustable?
No, the thermal-magnetic trip unit is fixed. Both the long-time (overload) and instantaneous (short circuit) trip functions are factory set and cannot be adjusted in the field.
Can I use an Eaton CAH2125 to replace an older Cutler-Hammer CAH2125?
Yes. Eaton acquired Cutler-Hammer, and they manufacture the exact same C-Frame breakers under the Eaton name. The CAH2125 is a direct, drop-in replacement for older Cutler-Hammer models with the same catalog number.
