Eaton / Cutler-Hammer EHD3100L Molded Case Circuit Breaker
- 100A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
EHD3100L
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
EHD3100L
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer EHD3100L - 100A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
80A 3 Pole Molded Case Circuit Breaker
70A 3 Pole Molded Case Circuit Breaker
60A 3 Pole Molded Case Circuit Breaker
Description
Engineered for industrial applications, the Eaton EHD3100L delivers robust thermal-magnetic protection. This 3-pole, 100A unit features a fixed LI trip function within a compact F-frame footprint. Designed for unit-mount configurations, it integrates into Eaton Series C panelboards and motor control centers. It supports existing infrastructure, while newer builds migrate to the PDG23F0100TFFJ. Rated 14kAIC at 480VAC, this HACR-rated breaker allows reverse feed wiring.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EHD3100L |
| Series | EHD |
| Amperage | 100A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 14-1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator, Rotary Handle |
|---|---|
| Accessories | Line and Load Lugs |
| Standards | CSA C22.2 No. 5, NEMA AB-1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
6 answersWhat does the L suffix in the EHD3100L catalog number indicate?
The L suffix indicates that the circuit breaker is factory equipped with both line and load side lug terminals. Without this suffix, standard Eaton F-frame breakers typically only include load side terminals.
Which panelboards are compatible with this F-frame circuit breaker?
This unit mounts directly into Eaton Series C panelboards, switchboards, and motor control centers that are designed to accept F-frame molded case circuit breakers.
What wire sizes and materials are accepted by the standard lugs on this breaker?
The included line and load lugs accept 14 AWG to 1/0 AWG wire. They are dual rated for use with either copper or aluminum conductors.
Is the EHD3100L suitable for use in heating, air conditioning, and refrigeration applications?
Yes, all Eaton Series C F-frame circuit breakers are HACR rated for use in HVACR equipment branch circuits.
Can this circuit breaker be reverse fed?
Yes, Eaton F-frame circuit breakers are suitable for reverse feed applications, allowing you to wire the line connection to either the top or bottom terminals.
Can I swap out the trip unit on this model to change the amperage?
No, this breaker features a fixed thermal and fixed magnetic trip unit. The trip unit is non-interchangeable, so the entire breaker must be replaced if a different amperage is required.
