Eaton / Cutler-Hammer HMCPS030H1C Motor Circuit Protector
- 30A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
HMCPS030H1C
Motor Circuit Protector
Brand
Eaton / Cutler-Hammer
SKU
HMCPS030H1C
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer HMCPS030H1C - 30A 3 Pole Motor Circuit Protector
New
Quantity
Quantity
Eaton / Cutler-Hammer HMCPS030H1C - 30A 3 Pole Motor Circuit Protector
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | HMCPS |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | F |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series C Motor Starters (with Electronic Overload Relays), Motor Control Centers |
| Wire Gauge | 14 AWG - 1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Non-Aluminum Terminals (Suffix C) |
| Standards | CSA C22.2 No. 5.1, IEC 60947-2, UL 489 |
| Approval | CE, CSA, UL, UR |
| Temp Rating | 40C |
Sold out
Quantity
Eaton / Cutler-Hammer HMCPS030H1C - 30A 3 Pole Motor Circuit Protector
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | HMCPS |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | F |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series C Motor Starters (with Electronic Overload Relays), Motor Control Centers |
| Wire Gauge | 14 AWG - 1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Non-Aluminum Terminals (Suffix C) |
| Standards | CSA C22.2 No. 5.1, IEC 60947-2, UL 489 |
| Approval | CE, CSA, UL, UR |
| Temp Rating | 40C |
Similar Items
Eaton / Cutler-HammerHMCPS050K2C
50A 3 Pole Motor Circuit Protector
Eaton / Cutler-HammerHMCPS007C0C
7A 3 Pole Motor Circuit Protector
Eaton / Cutler-HammerHMCPS003A0C
3A 3 Pole Motor Circuit Protector
Description
Built for heavy-duty motor applications, the Eaton HMCPS030H1C is a 3-pole, 30A motor circuit protector that provides instantaneous short-circuit defense. It is specifically engineered to work alongside Eaton Series C motor starters and electronic overload relays to ensure complete motor branch circuit safety. This unit mount protector features an adjustable magnetic trip range of 90A to 300A, giving engineers the flexibility to tune the response to specific motor loads.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Series | HMCPS |
| Amperage | 30A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | F |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series C Motor Starters (with Electronic Overload Relays), Motor Control Centers |
| Wire Gauge | 14 AWG - 1/0 AWG |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Magnetic Only |
|---|---|
| Trip Function Code | I |
| Trip Function | Instantaneous Only |
| Trip Adjustability | Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Non-Aluminum Terminals (Suffix C) |
| Standards | CSA C22.2 No. 5.1, IEC 60947-2, UL 489 |
| Approval | CE, CSA, UL, UR |
| Temp Rating | 40C |
