Eaton / Cutler-Hammer EGH2125FFB - 125A 2 Pole Molded Case Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU EGH2125FFB
Select Item Condition
Earn 1053 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Eaton / Cutler-Hammer EGH2125FFB - 125A 2 Pole Molded Case Circuit Breaker

New

$1053.32 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Designed for heavy-duty commercial use, the Eaton EGH2125FFB is a 2-pole, 125A molded case circuit breaker. It provides reliable LI protection through a fixed thermal-magnetic trip unit. This model features a bolt-on mounting style, allowing it to install securely into Eaton Pow-R-Line panelboards. Load side lugs and mounting hardware are included. With a 65kAIC rating at 480VAC, the breaker utilizes a current-limiting, blow-open contact design to minimize fault damage.

Specifications

Brand Eaton / Cutler-Hammer
Series EGH
Part Number EGH2125FFB
Amperage 125A
Voltage 240VAC, 480VAC, 600Y/347VAC, 250VDC
Poles 2
Phase 1
AIC Rating 100kA @ 240VAC, 65kA @ 480VAC, 35kA @ 600Y/347VAC, 42kA @ 250VDC
Mounting Style Bolt-On
Terminal Type Lugs
For Use With Eaton Pow-R-Line Panelboards
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 14-1/0 AWG (Cu/Al)
Max Wire 1/0 AWG
Min Wire 14 AWG
Available Options Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Handle Lock
Accessories Load Side Lugs, Mounting Hardware
Standards CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489
Approval CCC, CE, CSA, IEC, KEMA, UL
Temp Rating 40C
Construction Features Current Limiting, HACR Rated, High Interrupting Capacity
