Eaton / Cutler-Hammer EHB2040 Molded Case Circuit Breaker
- 40A
- 2 Pole
- Bolt-On
Eaton / Cutler-Hammer
EHB2040
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
EHB2040
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer EHB2040 - 40A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
Similar Items
10A 2 Pole Molded Case Circuit Breaker
100A 2 Pole Molded Case Circuit Breaker
Description
Built for heavy-duty commercial use, the Eaton EHB2040 2-pole, 40A molded case circuit breaker delivers reliable long-time and instantaneous (LI) protection with a 14kAIC rating at 480Y/277VAC. This bolt-on breaker mounts into Eaton Pow-R-Line C panelboards and is fully compatible with legacy Westinghouse F-Frame systems. It crosses over to the EHD2040 replacement SKU. The unit comes equipped with load side lugs and is HACR rated for heating, air conditioning, and refrigeration.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | EHB2040 |
| Series | EHB |
| Amperage | 40A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480Y/277VAC |
| Phase | 1 |
| AIC Rating | 18kA @ 240VAC, 14kA @ 480Y/277VAC |
| Frame Type | EHB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Pow-R-Line C Panelboards, Westinghouse F-Frame Panelboards |
| Wire Gauge | 14-2 AWG |
| Max Wire | 2 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | UL 489, CSA C22.2 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Non-Interchangeable Trip |
Product FAQs
4 answersWhat is the modern replacement for the obsolete EHB2040 circuit breaker?
The Eaton EHD2040 is the direct manufacturer recommended replacement for the EHB2040. Both are 40-amp, 2-pole breakers, but the EHD series is the current F-Frame equivalent for legacy EHB applications.
Can I install the EHB2040 in a standard residential load center?
No. The EHB2040 is a commercial bolt-on circuit breaker designed specifically for Eaton Pow-R-Line C and legacy Westinghouse F-Frame panelboards. It is not compatible with standard plug-on residential load centers.
Are the lugs on the EHB2040 rated for aluminum wire?
Yes, the standard load lugs accept both copper and aluminum conductors ranging from 14 AWG to 2 AWG. Always apply a listed oxide inhibitor when terminating aluminum wiring.
What does the 480Y/277VAC rating mean for the EHB2040?
This slash voltage rating indicates the breaker is only suitable for solid-grounded wye systems where the line-to-ground voltage does not exceed 277V. It cannot be used on 480V ungrounded or corner-grounded delta systems.
