Eaton / Cutler-Hammer JDC3250 Molded Case Circuit Breaker
- 250A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
JDC3250
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
JDC3250
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer JDC3250 - 250A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Eaton / Cutler-Hammer JDC3250 - 250A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | JDC3250 |
| Series | JDC |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 100kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers, Legacy Westinghouse Panelboards |
| Wire Gauge | 8 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed |
Quantity
Eaton / Cutler-Hammer JDC3250 - 250A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | JDC3250 |
| Series | JDC |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 100kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers, Legacy Westinghouse Panelboards |
| Wire Gauge | 8 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed |
Similar Items
200A 3 Pole Molded Case Circuit Breaker
175A 3 Pole Molded Case Circuit Breaker
150A 3 Pole Molded Case Circuit Breaker
Description
Part of the Series C family, the Eaton JDC3250 molded case circuit breaker delivers 250A of industrial power distribution. It provides reliable protection with an adjustable magnetic trip unit. This unit-mount breaker installs into Eaton Series C panelboards, switchboards, and motor control centers, replacing legacy Westinghouse J-Frames. Rated 100 kAIC at 480V, this current-limiting MCCB is HACR rated and supports reverse feed applications.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | JDC3250 |
| Series | JDC |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 200kA @ 240VAC, 100kA @ 480VAC, 35kA @ 600VAC, 22kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Eaton Series C Panelboards, Switchboards, Motor Control Centers, Legacy Westinghouse Panelboards |
| Wire Gauge | 8 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, High Interrupting Capacity, Reverse Feed |
Product FAQs
6 answersCan the Eaton JDC3250 replace an older Westinghouse JDC3250 breaker?
Yes. Eaton acquired the Westinghouse distribution equipment division and continued manufacturing the Series C line. The Eaton JDC3250 is a direct replacement for legacy Westinghouse JDC3250 breakers, sharing the same physical dimensions, mounting footprint, and electrical ratings.
What is the difference between the Eaton JD, HJD, and JDC circuit breakers?
The prefix indicates the interrupting capacity (AIC) at 480VAC. The JD frame offers standard interrupting ratings, the HJD provides high interrupting capacity, and the JDC is the ultra-high interrupting, current-limiting version rated at 100kA at 480VAC.
What lug kit is standard for the JDC3250 circuit breaker?
The standard line and load lug kit for the 250A J-frame is the TA250KB. It accepts aluminum or copper wire ranging from 8 AWG to 350 kcmil.
How is the magnetic trip adjusted on the JDC3250?
The instantaneous magnetic trip is adjusted using a dial on the face of the trip unit. For a 250A Series C breaker, the magnetic pickup range can typically be set between 5 and 10 times the continuous current rating, which corresponds to 1250A to 2500A.
Is the JDC3250 suitable for reverse-feed applications?
Yes. Series C J-frame thermal-magnetic circuit breakers without interchangeable trip units, like the JDC3250, are suitable for reverse-feed applications.
What does the LI trip function code mean on this breaker?
LI stands for Long-Time and Instantaneous protection. The Long-Time function provides thermal overload protection with an inverse time delay, while the Instantaneous function provides immediate magnetic tripping during short-circuit faults.
