Eaton / Cutler-Hammer JGE3250FAG Molded Case Circuit Breaker
- 250A
- 3 Pole
- Unit Mount
Eaton / Cutler-Hammer
JGE3250FAG
Molded Case Circuit Breaker
Brand
Eaton / Cutler-Hammer
SKU
JGE3250FAG
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Eaton / Cutler-Hammer JGE3250FAG - 250A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
Eaton / Cutler-HammerJGE3200FAG
200A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerJGE3175FAG
175A 3 Pole Molded Case Circuit Breaker
Eaton / Cutler-HammerJGE3150FAG
150A 3 Pole Molded Case Circuit Breaker
Description
Designed for heavy-duty industrial use, this 250A molded case circuit breaker belongs to the Eaton Series G lineup. It delivers reliable long-time and instantaneous (LI) protection for commercial facilities and manufacturing plants. The JG-frame unit mounts into Eaton Series G panelboards, switchboards, and motor control centers. It also replaces older J3250 models, requiring a specific adapter for integration into legacy Series C enclosures.Specifications
| Brand | Eaton / Cutler-Hammer |
|---|---|
| Part Number | JGE3250FAG |
| Series | JGE |
| Amperage | 250A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Frame Type | JG |
|---|---|
| Terminal Type | Lugs |
| For Use With | Eaton Series G Panelboards, Switchboards, Motor Control Centers |
| Wire Gauge | 8 AWG - 350 kcmil (Al/Cu) |
| Max Wire | 350 kcmil |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Handle Mechanism, Motor Operator |
|---|---|
| Accessories | Line and Load Terminals (TA250FJ), Metric Mounting Hardware |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, HACR, IEC, KEMA, UL |
| Temp Rating | 40C |
| Construction Features | 80% Rated, HACR Rated |
