Eaton / Cutler-Hammer QBGFEP1040 - 40A GFEP Miniature Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU QBGFEP1040
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

Eaton / Cutler-Hammer QBGFEP1040 - 40A GFEP Miniature Circuit Breaker

Brand Eaton / Cutler-Hammer
SKU QBGFEP1040
Select Item Condition
Earn 269 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Eaton / Cutler-Hammer QBGFEP1040 - 40A GFEP Miniature Circuit Breaker

New

$269.50 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Rated 10 kAIC at 120VAC, the Eaton QBGFEP1040 is a 1-pole, 40A equipment protection breaker. It provides a 30mA ground fault threshold to prevent damage to industrial machinery and heat trace systems without nuisance tripping. Engineered for secure connections, this bolt-on unit installs into Eaton Pow-R-Line panelboards. The breaker features box lug terminals accommodating 14-4 AWG wire. This Quicklag family breaker utilizes fixed thermal-magnetic trip technology and is HACR rated.

Specifications

Brand Eaton / Cutler-Hammer
Series QBGFEP
Amperage 40A
Voltage 120VAC
Poles 1
Phase 1
AIC Rating 10kA @ 120VAC
Special Classification GFEP
Mounting Style Bolt-On
Terminal Type Box Lugs
For Use With Eaton Pow-R-Line Panelboards
Trip Technology Thermal Magnetic
Trip Function Code LIG
Trip Function Long-Time, Instantaneous, Ground Fault
Trip Adjustability Fixed Thermal, Fixed Magnetic
Wire Gauge 14-4 AWG
Max Wire 4 AWG
Min Wire 14 AWG
Available Options Padlock Attachment, Auxiliary Switch, Bell Alarm
Accessories Load Side Lugs Included
Standards CSA C22.2 No. 5, UL 1053, UL 489
Approval CSA, HACR, UL
Temp Rating 40C
Construction Features HACR Rated, Non-Interchangeable Trip
