ABB / General Electric THQC2150 Molded Case Circuit Breaker
- 50A
- 2 Pole
- DIN Rail
ABB / General Electric
THQC2150
Molded Case Circuit Breaker
Brand
ABB / General Electric
SKU
THQC2150
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
ABB / General Electric THQC2150 - 50A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
ABB / General Electric THQC2150 - 50A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQC2150 |
| Series | THQC |
| Amperage | 50A |
| Poles | 2 |
| Mounting Style | DIN Rail |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | DIN Rail Systems, OEM Panels, Enclosures, Control Panels |
| Wire Gauge | 8-3 AWG (Cu), 8-2 AWG (Al) |
| Max Wire | 3 AWG (Cu), 2 AWG (Al) |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 10C to 50C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break, Non-Interchangeable Trip, Visual Trip Indicator |
Sold out
Quantity
ABB / General Electric THQC2150 - 50A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQC2150-R |
| Series | THQC |
| Amperage | 50A |
| Poles | 2 |
| Mounting Style | DIN Rail |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | DIN Rail Systems, OEM Panels, Enclosures, Control Panels |
| Wire Gauge | 8-3 AWG (Cu), 8-2 AWG (Al) |
| Max Wire | 3 AWG (Cu), 2 AWG (Al) |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 10C to 50C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break, Non-Interchangeable Trip, Visual Trip Indicator |
Similar Items
ABB / General ElectricTHQC2145WL
45A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTHQC2160
60A 2 Pole Molded Case Circuit Breaker
ABB / General ElectricTHQC2160WL
60A 2 Pole Molded Case Circuit Breaker
Description
Delivering 50 amps of reliable overcurrent protection, the GE THQC2150 is a 2-pole molded case circuit breaker from the trusted Q-Line series. It is engineered to safeguard electrical systems operating at 120/240VAC. Designed for maximum integration flexibility, this compact breaker mounts into standard DIN rail systems and OEM enclosures. Unlike "WL" models, this specific unit is supplied with load-side lugs only, catering to specialized installation requirements.Specifications
| Brand | ABB / General Electric |
|---|---|
| Part Number | THQC2150 |
| Series | THQC |
| Amperage | 50A |
| Poles | 2 |
| Mounting Style | DIN Rail |
| Voltage | 120/240VAC |
| Phase | 1 |
| AIC Rating | 10kA @ 120/240VAC |
| Terminal Type | Lugs |
|---|---|
| For Use With | DIN Rail Systems, OEM Panels, Enclosures, Control Panels |
| Wire Gauge | 8-3 AWG (Cu), 8-2 AWG (Al) |
| Max Wire | 3 AWG (Cu), 2 AWG (Al) |
| Min Wire | 8 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | HACR, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 10C to 50C |
| Construction Features | HACR Rated, Common Trip, Quick-Make/Quick-Break, Non-Interchangeable Trip, Visual Trip Indicator |
Product FAQs
6 answersHow is the THQC2150 circuit breaker mounted inside an electrical enclosure?
The THQC2150 is a lug-to-lug (cable-in, cable-out) miniature breaker that typically mounts onto a standard 35mm DIN rail. It can also be secured directly to a backpan using compatible GE Q-Line screw-type mounting plates or slide-on metal mounting feet.
What wire sizes and materials are compatible with the THQC2150 terminals?
The built-in line and load lugs accept 8 to 3 AWG copper (Cu) wire, or 8 to 2 AWG aluminum (Al) wire.
Why might the THQC2150 arrive with ABB branding instead of General Electric?
ABB acquired GE Industrial Solutions in 2018. Because of this transition, Q-Line breakers like the THQC2150 may be labeled with either the ABB or General Electric logo depending on the manufacturing date. Both versions are mechanically and electrically identical.
Can auxiliary contacts or shunt trips be utilized with the THQC2150?
Yes, Q-Line miniature circuit breakers can be ordered or fitted with auxiliary contact switches and shunt trip accessories to support remote status signaling and automated tripping in control panels.
Can the THQC2150 be applied in 277V or 480V commercial systems?
No, the THQC2150 is strictly rated for a maximum of 120/240V AC. Applying this breaker to a 277V or 480V distribution system exceeds its design ratings and creates a severe safety hazard.
Are the thermal and magnetic trip elements adjustable on the THQC2150?
No. The breaker features a completely fixed thermal-magnetic trip unit with non-interchangeable long-time and instantaneous (LI) trip functions. The 50-amp overcurrent threshold cannot be altered in the field.
