Siemens 3VA5135-6ED11-0AA0 Molded Case Circuit Breaker
- 35A
- 1 Pole
- Panel Mount
Siemens
3VA5135-6ED11-0AA0
Molded Case Circuit Breaker
Brand
Siemens
SKU
3VA5135-6ED11-0AA0
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens 3VA5135-6ED11-0AA0 - 35A 1 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
35A 3 Pole Molded Case Circuit Breaker
35A 3 Pole Molded Case Circuit Breaker
Description
Engineered for commercial and industrial power distribution, the Siemens 3VA5135-6ED11-0AA0 is a 1-pole, 35A molded case circuit breaker from the advanced 3VA5 frame group. It provides reliable line protection using a TM210 fixed thermal-magnetic trip unit. This panel-mount MCCB installs into Siemens P1, P2, and P3 panelboards. It serves as a modernized replacement for legacy HED41B035 (ED Frame) breakers. Rated at 150kAIC at 120V, it features a current-limiting, HACR-rated design.Specifications
| Brand | Siemens |
|---|---|
| Series | 3VA5 |
| Amperage | 35A |
| Poles | 1 |
| Mounting Style | Panel Mount |
| Voltage | 120VAC, 277VAC, 125VDC, 347VAC |
| Phase | 1 |
| AIC Rating | 150kA @ 120VAC, 50kA @ 277VAC, 30kA @ 125VDC, 18kA @ 347VAC |
| Frame Type | 3VA51 |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Auxiliary Switch, Alarm Switch, Shunt Trip, Undervoltage Release, Motor Operator, Lugs, Handle Tie, Handle Lock, Padlock Attachment |
|---|---|
| Accessories | None (Without connection) |
| Standards | IEC 60947-2, UL 489 |
| Approval | CE, CSA, EAC, IEC, UL, VDE |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip, Trip-Free Mechanism, High Interrupting Capacity |
Product FAQs
6 answersWhich Siemens panelboards accept the 3VA5135-6ED11-0AA0 circuit breaker?
This 1-pole breaker is designed for installation in Siemens P1, P2, and P3 panelboards. Depending on the age and configuration of your panel, a specific 3VA mounting adapter kit may be required.
Can the 3VA51 frame replace legacy Siemens circuit breakers?
Yes, the 3VA51 series is the recommended modern replacement for discontinued Siemens ED4, ED6, BQD, and NGB frame breakers. Retrofitting into older panelboards requires the appropriate 3VA adapter kit.
What is the maximum frame rating for the 3VA5135-6ED11-0AA0?
This breaker utilizes the Siemens 3VA51 frame, which supports a maximum continuous current rating of 125 amps.
Is the 3VA5135-6ED11-0AA0 rated for direct current systems?
Yes, this thermal-magnetic breaker is rated for 125VDC applications with a 30kA interrupting capacity. It is suitable for use in DC control circuits and battery backup systems.
Are the trip settings adjustable on the 3VA5135-6ED11-0AA0?
No, this model is equipped with a TM210 thermal-magnetic trip unit that features fixed long-time (thermal) and fixed instantaneous (magnetic) protection. The trip curve cannot be modified in the field.
Is the 3VA5135-6ED11-0AA0 approved for reverse feed applications?
Yes, Siemens 3VA5 thermal-magnetic circuit breakers are UL listed for reverse feed installations, allowing power to be supplied from either the line or load side terminals.
