Siemens 3VA5222-6ED61-0AA0 Molded Case Circuit Breaker
- 225A
- 2 Pole
- Panel Mount
Siemens
3VA5222-6ED61-0AA0
Molded Case Circuit Breaker
Brand
Siemens
SKU
3VA5222-6ED61-0AA0
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens 3VA5222-6ED61-0AA0 - 225A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
100A 2 Pole Molded Case Circuit Breaker
100A 2 Pole Molded Case Circuit Breaker
90A 2 Pole Molded Case Circuit Breaker
Description
Engineered with a 2-pole configuration inside a 3-pole housing, this 225A molded case circuit breaker provides essential long-time and instantaneous (LI) protection. It is suited for commercial and marine applications. Designed to fit Siemens P2 and P3 panelboards. It also functions as a replacement for legacy HFD62B225 breakers, simplifying facility upgrades. Featuring a TM210 fixed thermal-magnetic trip unit, it achieves a 65 kAIC rating at 480VAC. It is HACR rated and current limiting.Specifications
| Brand | Siemens |
|---|---|
| Part Number | 3VA5222-6ED61-0AA0 |
| Series | 3VA5 |
| Amperage | 225A |
| Poles | 2 |
| Mounting Style | Panel Mount |
| Voltage | 240VAC, 480VAC, 600VAC, 500VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 85kA @ 500VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P2, P3 Panelboards, Switchboards |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Motor Operator, Rotary Handle, Handle Lock, Padlock Attachment, Busbar System, Lug Kits |
|---|---|
| Accessories | None (Nut Keeper) |
| Standards | IEC 60947-2, UL 489, HACR |
| Approval | ABS, CE, CSA, EAC, IEC, RCM, UL, VDE |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Reverse Feed, 2-Pole in 3-Pole Housing |
Product FAQs
4 answersWhich Siemens panelboards are compatible with the 3VA5222-6ED61-0AA0 breaker?
This breaker is designed for use with Siemens P2 and P3 panelboards, as well as compatible Siemens switchboards.
Is this breaker suitable for direct current (DC) applications?
Yes, this molded case circuit breaker is rated for DC applications up to 500V DC, providing an interrupting capacity of 85kA at that voltage.
What protection functions are included in the LI trip unit?
The LI designation indicates it provides Long-Time and Instantaneous protection. This thermal-magnetic trip unit offers fixed thermal overload protection (Long-Time) and fixed magnetic short-circuit protection (Instantaneous).
How is the 3VA5222-6ED61-0AA0 connected within a panel?
It utilizes a feed-thru connection type for panel mounting and comes equipped with lug terminals for securing the line and load conductors.
