Siemens B215H Molded Case Circuit Breaker
- 15A
- 2 Pole
- Bolt-On
Siemens
B215H
Molded Case Circuit Breaker
Brand
Siemens
SKU
B215H
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens B215H - 15A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens B215H - 15A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | B215H |
| Series | BLH |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC, 22kA @ 120/240VAC |
| Frame Type | B |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
Sold out
Quantity
Siemens B215H - 15A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | B215H-R |
| Series | BLH |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC, 22kA @ 120/240VAC |
| Frame Type | B |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
Similar Items
70A 2 Pole Molded Case Circuit Breaker
80A 2 Pole Molded Case Circuit Breaker
90A 2 Pole Molded Case Circuit Breaker
Description
Engineered for commercial applications, the Siemens B215H is a 2-pole, 15A molded case circuit breaker from the BLH series. It provides reliable thermal-magnetic protection with long-time and instantaneous trip functions. This bolt-on breaker installs into Siemens P1 through P5 panelboards. It also serves as a direct substitute for BAB2015H and QOB215VH models, offering flexible integration into existing systems. The unit features a 22kAIC interrupting capacity at 240VAC and is HACR rated.Specifications
| Brand | Siemens |
|---|---|
| Part Number | B215H |
| Series | BLH |
| Amperage | 15A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 120/240VAC |
| Phase | 1 |
| AIC Rating | 22kA @ 240VAC, 22kA @ 120/240VAC |
| Frame Type | B |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3, P4, P5 Panelboards |
| Wire Gauge | 14-10 AWG (Cu), 12-10 AWG (Al) |
| Max Wire | 10 AWG |
| Min Wire | 14 AWG (Cu), 12 AWG (Al) |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Padlock Attachment, Handle Tie |
|---|---|
| Standards | CSA C22.2 No. 5, UL 489 |
| Approval | CSA, HACR, UL |
| Temp Rating | 40C |
Product FAQs
6 answersWhich panelboards are compatible with the Siemens B215H circuit breaker?
This bolt-on breaker is designed for installation in Siemens P1, P2, P3, P4, and P5 commercial panelboards. It will not fit in standard residential plug-on load centers.
What is the difference between the Siemens BL and BLH series breakers?
The primary difference is the short-circuit interrupting rating. Standard BL series breakers are rated for 10kAIC, whereas the BLH series, including the B215H, provides a higher interrupting capacity of 22kAIC at 120/240VAC.
What wire sizes are accepted by the terminals on the B215H?
The load lugs on this 15-amp breaker accept 14 to 10 AWG copper conductors or 12 to 10 AWG aluminum conductors.
Is the Siemens B215H a plug-on or bolt-on breaker?
The B215H is a bolt-on circuit breaker. It physically bolts onto the panelboard bus bars, providing a secure, vibration-resistant connection typical for commercial and industrial environments.
What type of protection does the B215H provide?
It features a fixed thermal-magnetic trip unit with LI (Long-Time and Instantaneous) functions. The thermal element protects against sustained overloads, while the magnetic element trips instantly during a short circuit.
Can the B215H be used in older ITE panelboards?
Yes, Siemens manufactures the B215H as a direct replacement for legacy 15-amp, 2-pole, 22kAIC bolt-on breakers originally made by ITE and Gould for compatible panelboards.
