Siemens ED63B080 Molded Case Circuit Breaker
- 80A
- 3 Pole
- Bolt-On
Siemens
ED63B080
Molded Case Circuit Breaker
Brand
Siemens
SKU
ED63B080
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens ED63B080 - 80A 3 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens ED63B080 - 80A 3 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED63B080 |
| Series | ED6 |
| Amperage | 80A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Quantity
Siemens ED63B080 - 80A 3 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | ED63B080-R |
| Series | ED6 |
| Amperage | 80A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Similar Items
70A 3 Pole Molded Case Circuit Breaker
100A 3 Pole Molded Case Circuit Breaker
60A 3 Pole Molded Case Circuit Breaker
Description
Providing essential overcurrent protection, the Siemens ED63B080 is an 80A, 3-pole molded case circuit breaker for industrial environments. This Sentron ED frame breaker is configured for bolt-on mounting, ensuring a secure fit within Siemens P1, P2, and P3 panelboards. With an interrupting rating of 25 kAIC at 480VAC, the unit relies on fixed thermal and magnetic trip elements. It is HACR rated and reverse feed capable.Specifications
| Brand | Siemens |
|---|---|
| Part Number | ED63B080 |
| Series | ED6 |
| Amperage | 80A |
| Poles | 3 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
|---|---|
| Accessories | Load Side Lugs Included |
| Standards | CSA C22.2 No. 5, HACR Rated, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Reverse Feed, Non-Interchangeable Trip |
Product FAQs
7 answersCan the Siemens ED63B080 be installed in a standard residential load center?
No, this is a bolt-on ED frame breaker designed specifically for commercial and industrial Siemens P1, P2, and P3 panelboards, as well as compatible switchboards. It will not fit in standard plug-on residential load centers.
Is the ED63B080 suitable for reverse feed applications?
Yes, Siemens ED frame circuit breakers, including the ED63B080, are reverse feed capable. This allows the breaker to be back-fed when required by the panelboard configuration.
Is the ED63B080 circuit breaker HACR rated?
Yes, this Sentron series breaker is HACR rated, meaning it is certified for use with heating, air conditioning, and refrigeration equipment.
Are lugs included with the ED63B080, or do they need to be purchased separately?
Standard load-side lugs are included and factory-installed on this bolt-on breaker. They are dual-rated for both copper and aluminum conductors, so a separate lug kit is not required for typical panelboard installations.
Can the Siemens ED63B080 replace an older I-T-E ED63B080?
Yes. Siemens acquired the I-T-E brand, and the modern Siemens ED63B080 serves as a direct, drop-in replacement for legacy I-T-E breakers with the exact same catalog number.
What is the difference between the Siemens ED43B080 and the ED63B080?
The primary difference is their maximum voltage rating. The ED43B080 is rated for a maximum of 480VAC, whereas the ED63B080 is rated for up to 600VAC. Both share the same physical ED frame footprint.
What is the difference between the ED63B080 and the ED63B080L?
The ED63B080 is a bolt-on circuit breaker designed for panelboard installations, featuring load-side lugs only. The ED63B080L is the unit-mount version, which includes both line and load lugs for standalone, cable-in and cable-out applications.
