Siemens HEB2B020B Molded Case Circuit Breaker
- 20A
- 2 Pole
- Bolt-On
Siemens
HEB2B020B
Molded Case Circuit Breaker
Brand
Siemens
SKU
HEB2B020B
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HEB2B020B - 20A 2 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
15A 2 Pole Molded Case Circuit Breaker
30A 2 Pole Molded Case Circuit Breaker
35A 2 Pole Molded Case Circuit Breaker
Description
Designed for commercial power distribution, the HEB2B020B provides thermal-magnetic protection for 20A circuits. This EG-frame breaker features fixed long-time and instantaneous trip functions. The bolt-on design ensures a secure connection within Siemens P3, P4, and P5 panelboards. This legacy unit is replaced by the HEG2B020B model. Rated at 65kAIC at 480VAC, it delivers high interrupting capacity. HACR and HID ratings make it versatile for HVAC and lighting loads.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HEB2B020B |
| Series | HEB |
| Amperage | 20A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600Y/347VAC, 125/250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600Y/347VAC, 42kA @ 125/250VDC |
| Frame Type | HEB |
|---|---|
| Terminal Type | Lugs |
| For Use With | Siemens P3, P4, P5 Panelboards |
| Wire Gauge | 14-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 14 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs Included (TA1EG10) |
| Standards | CSA C22.2 No. 5, HACR, HID, IEC 60947-2, UL 489 |
| Approval | CE, CSA, IEC, NOM, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, HID Rated, High Interrupting Capacity, Reverse Feed, Trip-Free Mechanism, Non-Interchangeable Trip |
