Siemens HHED62B060 Molded Case Circuit Breaker
- 60A
- 2 Pole
- Bolt-On
Siemens
HHED62B060
Molded Case Circuit Breaker
Brand
Siemens
SKU
HHED62B060
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HHED62B060 - 60A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens HHED62B060 - 60A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B060 |
| Series | HHED6 |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Extra High Interrupting Capacity, HACR Rated, Non-Interchangeable Trip, Reverse Feed |
Sold out
Quantity
Siemens HHED62B060 - 60A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B060-R |
| Series | HHED6 |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Extra High Interrupting Capacity, HACR Rated, Non-Interchangeable Trip, Reverse Feed |
Similar Items
50A 2 Pole Molded Case Circuit Breaker
45A 2 Pole Molded Case Circuit Breaker
80A 2 Pole Molded Case Circuit Breaker
Description
Part of the Sentron ED frame family, the Siemens HHED62B060 is a 2-pole, 60A molded case circuit breaker built for commercial applications. It features thermal-magnetic trip technology with fixed long-time and instantaneous (LI) protection. This bolt-on MCCB mounts into Siemens P1, P2, and P3 panelboards. It includes load lugs and accepts 10-1/0 AWG wire. Delivering an extra high interrupting capacity of 100kA at 240VAC, it ensures robust fault clearing and is fully HACR rated.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HHED62B060 |
| Series | HHED6 |
| Amperage | 60A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens P1, P2, P3 Panelboards, Switchboards |
| Wire Gauge | 10-1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Load Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, UL 489 |
| Approval | CSA, UL |
| Temp Rating | 40C |
| Construction Features | Extra High Interrupting Capacity, HACR Rated, Non-Interchangeable Trip, Reverse Feed |
Product FAQs
5 answersWhich Siemens panelboards are compatible with the HHED62B060 circuit breaker?
This bolt-on ED frame breaker is designed for installation in Siemens P1, P2, and P3 panelboards, as well as compatible Siemens switchboards.
What wire sizes and materials are accepted by the lugs on the HHED62B060?
The factory installed lugs on this breaker accept 10 AWG to 1/0 AWG copper or aluminum (Cu/Al) conductors.
Can the HHED62B060 be used in reverse feed applications?
Yes, this thermal magnetic ED frame breaker is suitable for reverse feed applications.
Is the HHED62B060 rated for use in DC voltage systems?
Yes, this 2 pole breaker is rated for up to 250VDC applications with a 10 kAIC interrupting capacity.
How does the HHED6 frame compare to other Siemens ED frame breakers like the ED4 or HED4?
The HHED6 series offers an extra high interrupting capacity compared to standard ED frames. While the ED4 is rated 18 kAIC at 480VAC and the HED4 is rated 42 kAIC at 480VAC, the HHED6 provides 65 kAIC at 480VAC.
