Siemens HHED62B070 Molded Case Circuit Breaker
- 70A
- 2 Pole
- Bolt-On
Siemens
HHED62B070
Molded Case Circuit Breaker
Brand
Siemens
SKU
HHED62B070
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HHED62B070 - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
Quantity
Siemens HHED62B070 - 70A 2 Pole Molded Case Circuit Breaker
New
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B070 |
| Series | HHED6 |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 10 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Sold out
Quantity
Siemens HHED62B070 - 70A 2 Pole Molded Case Circuit Breaker
Re-Certified
Quantity
| Brand | Siemens |
|---|---|
| Part Number | HHED62B070-R |
| Series | HHED6 |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 10 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Similar Items
60A 2 Pole Molded Case Circuit Breaker
90A 2 Pole Molded Case Circuit Breaker
50A 2 Pole Molded Case Circuit Breaker
Description
Built for commercial and industrial applications, the Siemens HHED62B070 is a 2-pole, 70A molded case circuit breaker from the Sentron ED-Frame family. It provides reliable thermal-magnetic protection for demanding electrical systems. This bolt-on MCCB mounts into Siemens P1, P2, and P3 panelboards, as well as compatible switchboards. Rated for 65kAIC at 480VAC and 100kAIC at 240VAC, it features an extra-high interrupting capacity to handle severe fault conditions.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HHED62B070 |
| Series | HHED6 |
| Amperage | 70A |
| Poles | 2 |
| Mounting Style | Bolt-On |
| Voltage | 240VAC, 480VAC, 600VAC, 250VDC |
| Phase | 1 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 18kA @ 600VAC, 10kA @ 250VDC |
| Terminal Type | Lugs |
|---|---|
| For Use With | Siemens Sentron Panelboards (P1, P2, P3), Switchboards, Enclosures |
| Wire Gauge | 10 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Alarm Switch, Undervoltage Release |
|---|---|
| Accessories | Load Side Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CSA, HACR, IEC, UL |
| Temp Rating | 40C |
| Construction Features | HACR Rated, Extra High Interrupting Capacity, Non-Interchangeable Trip, Reverse Feed |
Product FAQs
5 answersWhich panelboards are compatible with the HHED62B070 circuit breaker?
This bolt-on ED frame breaker is designed for use in Siemens Sentron P1, P2, and P3 panelboards, as well as compatible Siemens switchboards and enclosures.
Can the Siemens HHED62B070 be reverse fed?
Yes. Standard Siemens thermal magnetic ED frame circuit breakers like the HHED62B070 do not have line and load markings, making them suitable for reverse feed applications.
What is the difference between Siemens ED4, HED4, and HHED6 circuit breakers?
All three belong to the Siemens Sentron ED frame family and share the same physical dimensions. The difference is their interrupting capacity. The HHED6 series offers the highest fault current rating, providing up to 65kAIC at 480V, compared to the lower ratings of the ED4 and HED4 models.
What wire sizes are accepted by the standard lugs on the HHED62B070?
The standard factory-installed lugs accept 10 AWG to 1/0 AWG copper or aluminum wire. Ensure you follow the manufacturer torque specifications during installation.
Will the HHED62B070 replace older I-T-E ED frame breakers?
Yes. Siemens acquired I-T-E, and the current Siemens Sentron ED frame breakers serve as direct replacements for legacy I-T-E breakers with the same frame size and mounting configuration.
