Siemens HHED63B050L Molded Case Circuit Breaker
- 50A
- 3 Pole
- Unit Mount
Siemens
HHED63B050L
Molded Case Circuit Breaker
Brand
Siemens
SKU
HHED63B050L
Quantity
Shop with Confidence
Add an extra year of protection in your cart.
Siemens HHED63B050L - 50A 3 Pole Molded Case Circuit Breaker
New
Quantity
Similar Items
50A 3 Pole Molded Case Circuit Breaker
50A 3 Pole Molded Case Circuit Breaker
Description
Designed for versatile standalone installations, the Siemens HHED63B050L is a 3-pole, 50A molded case circuit breaker from the Sentron ED frame family. This unit-mount version comes factory-equipped with line and load lugs, making it perfect for custom enclosures and industrial control panels. It utilizes a fixed thermal-magnetic trip unit to deliver reliable overcurrent protection. Boasting an extra-high interrupting capacity of 65 kAIC at 480VAC, it easily handles demanding environments.Specifications
| Brand | Siemens |
|---|---|
| Part Number | HHED63B050L |
| Series | HHED6 |
| Amperage | 50A |
| Poles | 3 |
| Mounting Style | Unit Mount |
| Voltage | 600VAC, 250VDC |
| Phase | 3 |
| AIC Rating | 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC, 30kA @ 250VDC |
| Frame Type | ED |
|---|---|
| Terminal Type | Lugs |
| For Use With | Enclosures, Switchboards, Control Panels |
| Wire Gauge | 10 AWG - 1/0 AWG (Cu/Al) |
| Max Wire | 1/0 AWG |
| Min Wire | 10 AWG |
| Trip Technology | Thermal Magnetic |
|---|---|
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Fixed Magnetic |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch |
|---|---|
| Accessories | Line and Load Lugs (LN1E100) |
| Standards | CSA C22.2 No. 5, HACR, IEC 60947-2, UL 489 |
| Approval | CSA, IEC, UL |
| Temp Rating | 40C |
| Construction Features | Extra High Interrupting Capacity, HACR Rated, Non-Interchangeable Trip, Reverse Feed, Trip-Free Mechanism |
