Siemens HQR23B225 - 225A 3 Pole Molded Case Circuit Breaker

Brand Siemens
SKU HQR23B225
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99
Free Shipping Over $99

Siemens HQR23B225 - 225A 3 Pole Molded Case Circuit Breaker

Brand Siemens
SKU HQR23B225
Select Item Condition
Earn 829 SuperPoints

Quantity
Planning a Big Order?
Bulk pricing available—let us know your needs for a quote.
Get a quote
Shop with Confidence
Enjoy a free 60-day warranty, extendable to 1 year at checkout.
Learn more

Siemens HQR23B225 - 225A 3 Pole Molded Case Circuit Breaker

New

$829.97 In stock

Quantity

DescriptionSpecificationsSuperClubWarranties
Description
Providing fixed thermal-magnetic trip functionality, the Siemens HQR23B225 is a robust 3-pole, 225A molded case circuit breaker from the Sentron QR frame series. It delivers long-time and instantaneous (LI) protection for commercial and industrial electrical systems. Featuring a bolt-on mounting style with load side lugs, it integrates seamlessly into Siemens P1, P2, and P3 panelboards as well as switchboards. Rated at 65kAIC at 240VAC, this breaker effectively replaces discontinued QJ frames.

Specifications

Brand Siemens
Series HQR
Amperage 225A
Voltage 240VAC
Poles 3
Phase 3
AIC Rating 65kA @ 240VAC
Mounting Style Bolt-On
Terminal Type Lugs
For Use With Siemens P1, P2, P3 Panelboards, Switchboards
Trip Technology Thermal Magnetic
Trip Function Code LI
Trip Function Long-Time, Instantaneous
Trip Adjustability Fixed
Wire Gauge 3 AWG - 300 kcmil (Al/Cu)
Max Wire 300 kcmil
Min Wire 3 AWG
Available Options Shunt Trip, Auxiliary Switch, Alarm Switch, Padlock Attachment
Accessories Load Side Lugs
Standards CSA C22.2 No. 5, UL 489
Approval CSA, HACR, UL
Temp Rating 40C
Construction Features HACR Rated, Reverse Feed, Push-to-Trip Button, High Interrupting Capacity, Non-Interchangeable Trip
